86 Procedures for installation of the switch
Table 15
Terminal emulation settings
Property
Baud Rate
Data Bits
Stop Bits
Parity
Flow Control

Assigning IP parameters using the UI button

This procedure describes the steps to assign IP parameters using the UI
button.
Procedure Steps
Step
1
2
3
4

Assigning IP parameters using Web-based Management

This procedure describes the steps you use to assign IP parameters to the
5000 Series switch using the Web-based Management Interface.
Copyright © 2008–2009 Nortel Networks
Action
Press and hold the UI button for 3 seconds.
The unit will now be in configuration mode. The Status LED will
now change to a blinking green status.
Press the UI button 5 times.
The Base LED and the Up and Down LEDs will now be steady
amber to indicate that the button press was recognized.
Press the UI button and hold in for 3 seconds to confirm the
command.
The In-Use IP address will now be changed to 192.168.192.168.
The color and status of the Status LED will turn to steady green
once the command has been accepted. If the command is
rejected, the Status LED turns amber blinking.
Initial IP configuration using the UI button is now complete. To
continue with switch configuration, access the switch through the
NNCLI, Web-based Management Interface, or Device Manager.

ERS 5000 Series Installation

NN47200-300 04.03
13 April 2009
Value
9600 bps
8
1
None
None
--End--
