Assigning IP parameters using the console menu and NNCLI

Procedure Steps
Step
1
2
3
4
5
6
7
8
Job aid
Any terminal or PC with an appropriate terminal emulator can be used
as the management station. The following table lists the parameters that
must be used with any terminal emulation software used to connect to the
switch.
Copyright © 2008–2009 Nortel Networks
Assign an IP address to the switch.
•
For a standalone switch, enter a value in the In-Band Switch
IP Address field in dotted-decimal notation.
•
For a stack configuration, enter a value in the In-Band Stack
IP Address field in dotted-decimal notation.
In the In-Band Subnet Mask field enter the appropriate subnet
mask in dotted-decimal notation.
In the Default Gateway field, enter the appropriate default
gateway in dotted-decimal notation.
Press CTRL + C to return to the main menu.
Action
Connect a terminal to the console port of the switch.
Set the terminal protocol on the terminal or terminal emulation
program to VT100 and VT100/ANSI.
Connect to the switch using the terminal or terminal emulation
application.
After the Nortel banner is displayed, press CTRL + Y to display
the main menu.
Select Command Line Interface. . . from the main menu.
Enter the Global Configuration command mode using the
enable and configure terminal commands.
In the Global Configuration command mode, use the ip
address command to set the switch or stack IP address.
Initial IP configuration is now complete. To continue with
configuration operations, use the appropriate CLI commands. To
disconnect from the switch use the logout command to return
to the Console Menu and select Logout from the main menu.

ERS 5000 Series Installation

NN47200-300 04.03
13 April 2009
IP address information configuration 85
