Procedure Steps
Step
1
2
3
4
5
IP address information configuration
The following sections contain information necessary to configure IP
address parameters on the switch.

Connecting a console

This procedure describes the steps to connect a console.
Copyright © 2008–2009 Nortel Networks
Action
Remove the transceiver from the protective packaging.
Verify that the transceiver is the correct model for the network
configuration.
Grasp the transceiver between the thumb and forefinger.
Insert the transceiver into the proper module on the switch.
Apply a light pressure to the transceiver until it clicks and locks
into position in the module.
Remove the dust cover from the transceiver optical bores.

ERS 5000 Series Installation

NN47200-300 04.03
13 April 2009

IP address information configuration 83

--End--
