68 Procedures for installation of the switch

Mounting on a wall

This procedure describes how to mount a 5000 Series switch on the wall.
Prerequisites
•
Phillips #2 screwdriver
•
Wall anchors and screws
One 5500 Series switch weighs as much as 11.6 lbs (5.26 kg), and one
1U 5600 Series switch weighs as much as 30 lbs (13.6 kg). Ensure you
choose fasteners appropriate for the weight of the unit. One person can lift
and install the 5500 Series switch. Nortel recommends that two people
lift and install a 5600 Series switch.
Procedure Steps
Step
1
2
Copyright © 2008–2009 Nortel Networks
Figure 10
Ethernet Routing Switch 5000 Series on a table or shelf
Action
Attach the brackets to each side of the device as shown in .
Secure the brackets to the wall using appropriate screws and
wall anchors (not provided) .

ERS 5000 Series Installation

NN47200-300 04.03
13 April 2009
--End--
--End--
