66 Procedures for installation of the switch

Switch placement

The following sections describes the various methods of mounting or
placing a switch.

Mounting on a table or shelf

This procedure describes how to mount 5000 Series switches on a table or
a shelf.
A single 5000 Series Switch can be installed on any flat surface. The
surface should be able to support the combined weight of the switch and
attached cables; between 15 and 20 lbs (7 to 9 kg) for a 5500 Series
switch, and between 21 and 33 lbs (9.5 to 15 kg) for a 5600 Series switch..
Procedure Steps
Step
1
Copyright © 2008–2009 Nortel Networks
5. Country-specific AC power cord or DC adapter
6. Power supply module and related documentation
CAUTION
Do not place a Nortel Ethernet Power Supply Unit 10 or Nortel
Ethernet Redundant Power Supply 15 on top of a Nortel
Ethernet Routing Switch 5500 Series. The switch housing of
a 5500 Series Nortel Ethernet Routing Switch is not strong
enough to support the weight of these units.
Action
Using Figure 9 "Attaching rubber footpads to a 5500 Series
switch" (page 67) as a guide, attach the provided rubber
footpads to the bottom of the switch in the locations shown.

ERS 5000 Series Installation

NN47200-300 04.03
13 April 2009
--End--
