BLUM FLATPAX OFFICE FURNITURE RANGE
DESK RETURN 1350mm X 450mm X 575mm
B - Visible Side Left
A - Visible Side Left
E - Fixed Shelf
HARDWARE
PRODUCT
Dufix
Minifix
Wooden Dowel
Plastic Glide Brown
ASSEMBLY GUIDE
F - Partition
D - Top
C - Floor Bottom
1
J - Back Panel
I - Front Panel
H - Fixed Shelf
G - Fixed Shelf
TOTAL NUMBER OF PANELS: 10
QTY
36
36
72
4

Advertisement

loading
Need help?

Need help?

Do you have a question about the BLUM FLATPAX and is the answer not in the manual?

Questions and answers

Related Manuals for PG BISON BLUM FLATPAX

Summary of Contents for PG BISON BLUM FLATPAX

  • Page 1 BLUM FLATPAX OFFICE FURNITURE RANGE ASSEMBLY GUIDE DESK RETURN 1350mm X 450mm X 575mm F - Partition B - Visible Side Left J - Back Panel A - Visible Side Left I - Front Panel D - Top E - Fixed Shelf...
  • Page 2 TOOLS REQUIRED Screw Driver Rubber Mallet Pozi Bit (PZ2) 8mm Drill Bit Cordless Drill (Pozidriv Head) GENERAL INSTRUCTIONS 1. Confirm that all panels (10) are in the package before assembling. 2. Check the white sticker on each panel for the labelling (A, B, C, D, E, F, G, H, I & J). 3.
  • Page 3 STEP 1 Connect panels G & H to panel I as shown. Refer to the holes on the diagram to determine the panel orientation. STEP 2 Connect panel J to panels G & H as shown. Refer to the holes on the diagram to determine the panel orientation.
  • Page 4 STEP 3 Connect panels G & H to panel F as shown. Refer to the holes on the diagram to determine the panel orientation. STEP 4 Connect panel E to panels A & B as shown. Refer to the holes on the diagram to determine the panel orientation.
  • Page 5 STEP 5 Connect panel E to panel F as shown. Refer to the holes on the diagram to determine the panel orientation. STEP 6 Connect panels A, B, F, I & J to panel D as shown. Refer to the holes the diagram to determine the panel orientation.
  • Page 6 STEP 7 Connect panel C to panel A, B, F, I & J as shown. Refer to the holes on the diagram to determine the panel orientation. STEP 8 50 mm 50 mm 10 mm 10 mm 50 mm 50 mm Using a rubber mallet, knock in the Plastic Glides in the shown positions on panel C.
