Table 4-4 Configuration #2, English Equivalent, Factory Default

4.4.4 Configuration Table Details

For example, when using Table 4-1 Configuration #1 Zone Factory Default Settings,
if the dialer sends in a Code 06, the SYSTEM 3505 will process an Alarm for Zone
06. If the dialer sends a code 26, Zone 06 is Secure. A code 65 indicates a Trouble
condition on Zone 15, a Code 74 indicates that Zone 15 is Secure. With Table 4-4
Configuration #2 English Equivalent Factory Default Settings, if the dialer sends the
code E9, the SYSTEM 3505 will respond to the Daily Test.
When the dialer sends an alarm code to the SYSTEM 3505, the system looks for the
code first in the English Equivalent table and then in the Zone Setting table. Codes
MUST NOT be duplicated within Configurations. The SYSTEM 3505 only reads the
first occurrence of the code. For example, a code 30 is used to indicate Daily Test
in the English Equivalent table and then it is reused to indicate an alarm in zone 08
in the Zone setting table. If the dialer sends an alarm code 30 for zone 8, the
SYSTEM 3505 would read it as a Daily Test. The alarm condition would never be
read because the SYSTEM 3505 found the first occurrence of a code 30 in the
English Equivalent table.
700289-0001 Rev. B 10/21
Process
Daily Test
Secure All
Opening
Closing
AC Failure
Ac Now OK
Line 1 Fault
Line 1 OK
Ground Fault
Ground Now OK
Battery Fail
Battery OK
Line 2 Fault
Line 2 OK
Data Loss
For
E9
-
-
-
-
-
-
-
-
-
-
-
-
-
-
