Silver Mobile TV Cart
Instruction Manual
SKU: STAND-TV09
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv09
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-TV09 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vivo STAND-TV09

Summary of Contents for Vivo STAND-TV09

  • Page 1 Silver Mobile TV Cart Instruction Manual SKU: STAND-TV09 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv09 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...

  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.

  • Page 3: Tools Needed

    TOOLS NEEDED 11lbs 11lbs (5kg) (5kg) Phillips Screwdriver CAMERA ASSEMBLY STEPS STEP 1 Insert Base (A) into Left Leg (B). Align the mounting holes and secure with M6x16mm Screws (S-B) and 4mm Allen Wrench (T-A). Repeat this step for Right Leg (C). Adjust caster height by loosening the nut with Wrench (T-B).
  • Page 4 STEP 3 Attach Support Plate (F) to Column (J) with M6x14mm Screws (S-F). Tighten screws using a Phillips screwdriver. Place Top Cover (L) on top of Column (J). STEP 4 Insert Sqaure Washers (S-A) into the slots in the back of Universal Plate (G). Slide VESA Brackets (I) onto Universal plate (G).
  • Page 5 STEP 5 Choose the appropriate bolts, washers and spacers (if necessary) according to the type of screen. Tighten all bolts but do not over tighten. Screw the adapter brackets onto the display. STEP 6 Hang Universal Plate (G) onto Support Plate (F), and secure with M5x8mm Screws (S-I). IMPORTANT: Make sure display is mounted correctly and that bolts are tightened safely before releasing display.
  • Page 6 STEP 8 Run cables through cable management slots. STEP 9 Attach Camera Shelf (N) to Connecting Plate (M) using M4x6mm Flathead Screws (S-D). Tighten M4x6mm Screws (S-E) into the back of Camera Shelf (N) and Connecting Plate (M). STEP 10 Attach Connecting Plate (M) to Column (J) at the desired height using M6x25mm Screws (S-C) and a Phillips screwdriver.
  • Page 7 STEP 11 OPTION A: Landscape View To rotate from portrait to landscape view, remove the two screws from the back of Support Plate (F). Turn the display, and secure with the previously removed screws. Install at least two screws diagonally to secure the display.
  • Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
