Tabletop TV Stand
Instruction Manual
SKU: STAND-TV00T
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv00t
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-TV00T
Summary of Contents for Vivo STAND-TV00T
- Page 1 Tabletop TV Stand Instruction Manual SKU: STAND-TV00T Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv00t GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 110lbs Failure to do so may result in serious injury. (49.90kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Connect Base Plate (A1,B1) to Junction Plate (A2,B2) using M6x10 bolts (C) as shown in diagram. Use Allen key (F) to tighten bolts. - Page 4 STEP 2 Connect the lower TV brackets (A4,B4) to the upper TV brackets (A5,B5) using M6 nuts (E). Use wrench (G) to tighten. NOTE: This step can be skipped for smaller TVs that do not require the height of the upper TV brackets.
- Page 5 STEP 3 Attach TV brackets to junction plates using M6x10 bolts (c) and M6 cap nuts (d). Secure using Allen key and wrench (f,g). Attach plastic covers (a3,b3) to junction plates by pressing tabs into holes. STEP 4 Attach assembled brackets to back of TV using bolts (F-L) and washers (C-E) according to mounting holes in TV.
- Page 6 STEP 5 OPTION A: Wood Stud Wall Drill a 1.75” (45mm) deep hole using a 5/32” (3.8mm) drill bit. Attach security wire (V) to hole using the M6x45 bolt with washer and tighten with a Phillips screwdriver. 45mm Q R ã P K U ã...
- Page 7 STEP 5 (Continued) Ensure that security wire has little or no slack between the wall and TV. This will greatly reduce the risk of tipping.
- Page 8 - 92% within < 3hr : < 15 M www.vivo-us.com AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
