Tabletop TV Stand
Instruction Manual
SKU: STAND-TV00L
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv00l
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-TV00L
Summary of Contents for Vivo STAND-TV00L
- Page 1 Tabletop TV Stand Instruction Manual SKU: STAND-TV00L Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv00l GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 88lbs Failure to do so may result in serious injury. (39.92kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Stick rubber feet (k) to bottom of glass base (c). Assemble upper and lower support columns (d1, d2) using M6x10 bolts (l) with 6.5x18x2 washers (u2), then attach support column to swivel pad (g) using M6x14 bolts (h) and tighten with Allen wrench (y). - Page 4 STEP 2 Attach TV plates (a1) to TV plate connector (a2) using M6x10 bolts (l) and washers (m) and tighten with the Allen wrench. Attach TV plate to support column at desired height using M6x10 bolts (l) and washers (m). Clip bubble level (C) onto plate to ensure the plate is level, then tighten bolts with the Allen wrench.
- Page 5 STEP 4 Hang TV with brackets on TV plate (a) as shown in diagram. Secure TV brackets using buckles (A) with M4x6 bolts (B) as shown. Route cables through cable management clips (j) on back of stand.
- Page 6 STEP 5 If your TV is located near a wall as shown in Diagram 5a, then a steel wire from security wire kit (z) can be attached for added security. Attach the two ends of the steel wire to the top two holes on the back of your TV as shown in Diagram 5b.
- Page 7 STEP 5 (Continued) OPTION B: Concrete/Brick Wall Drill 2” (50mm) deep holes using a 5/16” (or 8mm) drill bit, and press anchors into holes. Secure with screws and washers. 50 mm 8m m...
- Page 8 - 92% within < 3hr : < 15 M www.vivo-us.com AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
