Black TV Stand with Storage Shelf
Instruction Manual
SKU: STAND-TV07-S
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv07-s
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-TV07-S
Summary of Contents for Vivo STAND-TV07-S
- Page 1 Black TV Stand with Storage Shelf Instruction Manual SKU: STAND-TV07-S Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv07-s GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. Failure to do so may result in serious injury. 44lbs 11lbs Phillips Screwdriver (20kg) (5kg) SHELF ASSEMBLY STEPS STEP 1 Attach base (A) to feet (B) using x4 M6x60mm carriage bolts (L), x4 D6 washers (M), and x4 M6 lock nuts (N).
- Page 4 STEP 3 Slide the plastic cover (G) over the pole (C). Slide the top half of the pole back into the bottom half and secure using the hardware you removed in step 2. STEP 4 Attach the center pole (C) to the base (A) using x1 M6x65 carriage bolt (L) through the front of the base, D6 washer (M) and M6 lock nut (N).
- Page 5 OPTION A: VESA Plate Only Use (M-A or M-B) bolts along with (M-E) washers to attach the VESA plate (D) without the adapters to the TV monitor. Make sure the “VIVO” logo on the front is right side up. M-A/M- B...
- Page 6 Use bolts (M-A-M-D) along with washers (M-E, M-F) to secure VESA plate with the adapters to the back of your television. Make sure the “VIVO” logo on the front is right side up. For a curved television, spacer (M-G) may be required.
- Page 7 STEP 7 Remove clear protective film from both the shelf clamp plate (H) and mounting bracket (I). Partially insert M6x60 socket head bolts (Q) into the shelf using the 5mm Allen wrench (S) as shown. NOTE: Do not fully tighten screws at this time. STEP 8 Adjust as desired.
