Tab Mounting Dimensions
Measurements shown below are in inches and (mm). Note that DIN mounting is recommended over tab mounting. See
EC-BOS-8 UUKL. With no option modules added, allow at least 1.5" (38mm) clearance around all sides, and minimum 3" (76mm) at bottom for
1
WiFi antenna.
2
Option expansion module. Up to four (4) may be used. See
3
Distances between center of tabs from one unit to another unit.
Figure 10: EC-BOS-8 UUKL tab mounting dimensions
"Option Module and Capacity
"Mounting on DIN
Considerations," page 2
Rail" page 4.
9/10
