Installing the Device
2.3.2 Mounting the Device to a Panel
3.
Removing the Device
To remove the device from a DIN rail, do the following:
1.
2.
3.
2.3.2 Mounting the Device to a Panel
For panel installations, the RUGGEDCOM RS930L can be equipped with panel
adapters on the top and bottom of the chassis. The adapters allow the device to be
attached to a panel using screws.
To mount the device to a panel, do the following:
1.
2.
8
Push the device against the bottom of the DIN rail, then let go of the sliding
release to latch the device.
Insert a flathead screwdriver into the slot of the sliding release and move it
down.
1
DIN Rail
1
DIN Rail Adapter
2
Figure 2.2 Removing the Device from a DIN Rail
Swing the bottom of the device away from the DIN rail.
Lift the device off the DIN rail.
Prepare mounting holes in the panel where the device is to be installed.
Place the device against the panel and align the adapters with the mounting
holes.
2
Installation Manual, 11/2022, C79000-G8976-1034-11
3
1
2
1
RUGGEDCOM RS930L
