ASSEMBLY INSTRUCTION
CLEO BED
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult).
For most products, two
persons are recommended.
EASY
DIFFICULT
PRODUCT CODE: HOBED00076

Requirement for Assembly

2 PERSONS RECOMMENDED
2 PERSONS RECOMMENDED
1/1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HOBED00076 and is the answer not in the manual?

Questions and answers

Related Manuals for Furn Mill HOBED00076

Summary of Contents for Furn Mill HOBED00076

  • Page 1 ASSEMBLY INSTRUCTION CLEO BED PRODUCT CODE: HOBED00076 Requirement for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult). For most products, two persons are recommended.
  • Page 2 HARDWARE DETAIL ASSEMBLED PRODUCT HARDWARE QTY. Screw 3.5x30mm Screw 4 x 25mm Maxi Connector 100mm Allen bolt M8x70mm Allen key no.5 Dowel 8x40mm...
  • Page 3 Placed the PART-B, PART-C,PART-D and PART-G on the ground as shown. Now fix these with maxi connector at position A1,A2,A3, A4,A5 and A6 as shown in Fig. Fix the PART-E & PART-F with last assembled part using screws of 30 mm with the help of screw driver at position B1 , B2 and C1 and C2 respectively as shown in Fig.
  • Page 4 Flip the last assembled part and fix the PART-A(headboard) with last assembled part by using allen bolt with help of allen key at position D1,D2,D3,D4,D5 & D6 as shown in Fig.
  • Page 5 Place the PART-H (slates) as shown in Fig. (Top LVL slates will be fixed by niwar to each other and then 1st, 3rd, 6th, 9th and 12th last slate will be screwed on batten.) Your bed is ready.
  • Page 6 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
