ASSEMBLY INSTRUCTION

QUAINT CHAIR

ASSEMBLY RATING

The Assembly Rating is a 5-point

system that shows the degree of effort

needed in assembling a specific

product (with 1 being easy and 5 being

difficult).

For most products, two

persons are recommended.

EASY

DIFFICULT

PRODUCT CODE: HOCHR00297

Requirement for Assembly

2 PERSONS RECOMMENDED

1/6

Table of Contents

Do you have a question about the QUAINT HOCHR00297 and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTION QUAINT CHAIR PRODUCT CODE: HOCHR00297 Requirement for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult). For most products, two persons are recommended.
Page 2 HARDWARE DETAIL ASSEMBLED PRODUCT HARDWARE QTY. Allen Bolt -M8 X 30 mm Allen Bolt -M8 X 35 mm Allen Key no.5...
Page 3 STEP -1 STEP-2 Step 1. Fix the seat and LHS frame by the help of Allen bolt using Allen Key as shown in the figure. Step 2. Fix the RHS frame on last assembled part by the help of Allen bolt using Allen Key as shown in the figure.
Page 4 STEP-3 Step 3. Flip the chair in standing position and fix the back by the help of Allen bolt at position D1 and D2 with using Allen key as shown in the figure.
Page 5 Your Chair is ready to use...
Page 6 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
