ASSEMBLY INSTRUCTIONS
CALIFORNIA BED
CALIFORNIA BED
Product Code : HOBED00048
ASSEMBLY RATING
Requirement for Assembly
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult). For most products, two
persons are recommended.
EASY
DIFFICULT
2 PERSON RECOMMENDED
1/1
Advertisement
Table of Contents
Related Manuals for Furn Mill CALIFORNIA BED
Summary of Contents for Furn Mill CALIFORNIA BED
- Page 1 ASSEMBLY INSTRUCTIONS CALIFORNIA BED CALIFORNIA BED Product Code : HOBED00048 ASSEMBLY RATING Requirement for Assembly The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 HARDWARES ASSEMBLED PRODUCT (SCREW3.5X16) Bed Clamp 100mm-2nos Bed Clamp 150 mm-4 nos (BED CLAMP) (SCREW3.5X30) 16 nos (SCREW3.5X35) 8 nos L-Patti...
- Page 3 STEP 01 (Use screws 16mm) Bed clamp150mm Fix Part-B and Part -C by Bed clamp of 150mm with the help of screw 3.5x16mm screw by using screw DriverAs shown in Fig. STEP 02 Fix part -I and other side of part-C with bed clamp 150mm using 3.5x16mm screws using screw Driver similar to STEP 01 as shown in fig.
- Page 4 STEP 03 Fix the middle part i.e. Part-G and Part-F using bed clamp of 100mm and L-patti using screw of 3.5x16mm as shown infig. Use 35mm screws for leg STEP 04 Use 30mm screws Use 16mm screws Fix the Part -H and Part -J using screw of 35mm and 30mm .Also fix Buffer in leg By using 16mm screw as shown in fig.
- Page 5 STEP 05 Use 30 mm screws Fix the Part-A(headboard),Part-E& Part-K (Fabric panel) with screw of 30mm screw as shown in fig. STEP 06 Now place the Part-M(Seat Panels) on last assembled pat as shown in Fig. Place The mattress and Your Bed is Ready.
- Page 6 We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase. Your satisfaction is the greatest recognition we could have.
