ASSEMBLY INSTRUCTION
NIRVANA BED
NIRVANA BED
PRODUCT CODE: HOBED00029
Requirement for Assembly
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult).
For most products, two
persons are recommended.
EASY
DIFFICULT
2 PERSONS RECOMMENDED
1/1
Advertisement
Table of Contents
Related Manuals for Furn Mill Nirvana
Summary of Contents for Furn Mill Nirvana
- Page 1 ASSEMBLY INSTRUCTION NIRVANA BED NIRVANA BED PRODUCT CODE: HOBED00029 Requirement for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 HARDWARE DETAIL ASSEMBLED PRODUCT HARDWARE QTY. Barrel nut 6x13mm 12 nos Allen bolt 6x70mm 12 nos Screw 3.5x25 4 nos Allen Key No.4 1 nos...
- Page 3 STEP01 (Set the postion Of Barrel nut proper Using Screw driver.) Fix the Part -A(Headboard),Part-B(sides)&Part-E(FootBoard) with Barrel nut and Allen bolt with the help of Allen key at Defined Position D1,D2,D3,& D4 As shown in Fig.
- Page 4 STEP02 Screws Allen Bolt Fix the Part-C (middle part) with barrel nut and allen bolt at Position D5 & D6 similar as STEP01 . Also fix the Part-D(Leg) with screw of 25 mm at position S1 & S2 as shown in Fig.
- Page 5 STEP03 Place the Part-F(Strips Panel) on last Assembled in fixed dowel Part as Shown in the Fig. STEP04 Your Bed is Ready.
- Page 6 We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase. Your satisfaction is the greatest recognition we could have.
