ASSEMBLY INSTRUCTION

X COFFEE TABLE

PRODUCT CODE: HOTAB00029

X -TABLE

Requirement for Assembly

The Assembly Rating is a 5-point

system that shows the degree of effort

needed in assembling a specific

product (with 1 being easy and 5 being

difficult).

For most products, two

persons are recommended.

EASY

DIFFICULT

2 PERSONS RECOMMENDED

1/1

Table of Contents

Do you have a question about the X COFFEE TABLE and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTION X COFFEE TABLE PRODUCT CODE: HOTAB00029 X -TABLE Requirement for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult).
Page 2 HARDWARE DETAIL ASSEMBLED PRODUCT HARDWARE QTY. ALLEN BOLT(M8 x 20 mm) ALLEN KEY (No.5)
Page 3 STEP 01 STEP 02 Flip the PART-A(Top) as shown in Fix the Part-B(leg) and Part-C(leg) in slot as Fig. Shown in Fig. STEP 04 STEP 03 Fix the legs with the top with Allen bolt Turn The Table. using Allen Key at position A1,A2,A3 & A4 Your Table is Ready as shown Fig.
Page 4 We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase. Your satisfaction is the greatest recognition we could have.
