Instructions for installing and maintaining the
EcoPure 200
Order no. 340155
The points described in these
instructions must be observed
in all cases. Failure to do so
shall invalidate the warranty. For
any additional items purchased
through GRAF, you will receive
separate installation instructions
in the transport packaging.
The components
checked for any damage before
the system is transferred to the
trench. Damaged components
must not be used.
You can download any missing
instructions from www.graf.info
or request them from GRAF di-
rectly.
mail@graf.info
www.graf.info
GRAF EcoPure
Contents
1. GENERAL INFORMATION
1.1 Safety
2. TRANSPORT, STORAGE AND UNLOADING
2.1 Transport
2.2 Storage
2.3 Unloading
3. INSTALLATION CONDITIONS
4. TECHNICAL DATA
4.1 EcoPure 200 exterior
must be
4.2 EcoPure 200 housing
4.3 EcoPure 200 sectional drawing
5. INSTALLATION AND ASSEMBLY
5.1 Foundation
5.2 Pit
5.3 Connecting pipes
5.4 Distance to the downstream infiltration
5.5 Filling the trench
5.6 Positioning on a slope, embankment etc.
5.7 Groundwater
soils (e.g. loam)
5.8 Final assembly
5.8.1 Fitting telescopic dome shaft on tank
5.8.2 Installation of extension sleeve and telescopic dome
shaft
5.9 Suitable for pedestrian loading
5.10 Suitability for vehicle loading
5.11 Suitability for heavy goods vehicles
6. INSPECTION AND MAINTENANCE
6.1 Disposal
6.2 Maintenance intervals
6.2.1 Replacement intervals of the media bags
6.2.2 Replacing the media bags
6.2.3 Sludge trap maintenance
6.3 Vacuum removal of the sludge trap contents
6.4 Logbook
and cohesive
/
2
2
(non-water-permeable)
