4 ICS AirCal Delivery Head & Foot Switch
present. 3) If the ICS AirCal was tilted at more than 20° with the water pump running. If one of these criteria were met
please refer to
Caution
• Only
the ICS AirCal.
1. Turn off ICS AirCal and disconnect from the electrical wall outlet.
2. Wipe off any dust on the top of the ICS AirCal prior to opening the case to refill the reservoir.
3. Face the ICS AirCal front panel. On the back right side is a small cover. Using the Allen key (supplied with the irrigator
cradle) unscrew the cover and remove.
4. Using the Allen key unscrew the internal cover and remove.
5. Expand the funnel supplied with the ICS AirCal.
6. Place the funnel in the refill hole of the reservoir.
7. Pour water into the funnel to fill the reservoir.
8. Monitor the water level closely. Fill to the bottom of the lip. Do NOT overfill the reservoir.
9. If water was spilled into the small indentions where the internal cover is placed. Wipe up this excess water before
replacing the internal cover.
10. Replace the internal cover and tighten the screws.
11. Replace the external cover and tighten the screws.
12. Plug in the ICS AirCal to the electrical wall outlet and turn on ICS AirCal.
Caution
Due to the possibility of freezing during shipment, water must be drained from the reservoir before shipping
•
the ICS AirCal. See
4 ICS AirCal Delivery Head & Foot Switch
4.1 Delivery Head
The delivery head can be held in any way that is comfortable for the tester. Flow time activation is accomplished by an
activation trigger located on the delivery head. The otoscope light can be turned on and off using the button located on
the back of the handle below the lens.
Note
Turn light off when not in use.
•
16
Getting started ► 5 and follow the
use distilled water. Using common water from the tap will result in mineral deposits and will harm
Troubleshooting ► 28
for water removal instructions..
Filling and priming procedure ► 9 .
Natus Medical – ICS® AirCal
]
