3.5.2 Setting a new Airflow Rate
Turn the knob to the right of the airflow
increase the airflow and clockwise to decrease the airflow. The range for the airflow rate is 4 to 10 liters per minute. The
airflow rate is set based on the knob position.
The flow rate selection (actual only) will be indicated on the display panel. If the ICS AirCal is in operation mode, the
digital display shows the actual flow rate. If the ICS AirCal is in standby mode the display will be off.
3.6 Beep Volume
A beep will sound when the timer reaches 0 to alert the tester to stop irrigation. A 2000 Hz beep is presented.
3.6.1 Default Beep setting
The default Beep is set to level 2.
3.6.2 Setting a new beep volume
To adjust the beep volume, press and hold the beep
There are 4 levels for the beep volume. To change the beep volume stored default value, see
Default Values ► 15
3.7 Changing the Stored Default Values
Change all settings to the desired setting. Decide what temperature for the ICS AirCal to start up in. Press and hold either
the warm
peratures, startup temperature, duration timer and beep volume). A 1 second beep will be sounded to confirm that the
default settings have been stored. Remember, the default startup temperature of the ICS AirCal should match the tem-
perature of the first caloric protocol in your list (e.g. if you start with Left Cool - default the AirCal to start with Cool).
3.8 Water level display
The water level of the water in the reservoir is displayed. The
blue bar will display. The
and em p ty the bar will change from blue to orange this indicates that the water reservoir needs to be refilled. And
symbol indicates that the water reservoir is empty.
3.8.1 Refill Procedure:
Caution
Do NOT use this refill procedure if: 1) the ICS AirCal was just received from shipping dry. It needs to be filled
•
and primed, 2) If the water level in the display has gone to zero because user never refilled it when orange bar was
Natus Medical – ICS® AirCal
]
.
or cool temperature button for 3 seconds to set all default settings (warm and cool tem-
symbol indicates that the water reservoir is half full a blue bar will display. Between half full
button to adjust the flow rate. Turn the knob counterclockwise to
button until a beep is sounded that you want as the default.
symbol indicates that the water reservoir is full and a
