4 ICS AirCal Delivery Head & Foot Switch
4 ICS AirCal Delivery Head & Foot Switch
4.1 Delivery Head
The delivery head can be held in any way that is comfortable for the tester. Flow time activation is accomplished by an
activation trigger located on the delivery head. The otoscope light can be turned on and off using the button located on
the back of the handle below the lens.
Note
Turn light off when not in use.
•
Note Caution symbol indicates that the inner speculum should never be placed in the ear without an Outer Dis-
•
posable Speculum attached to it.
A. Inner Speculum
B. Flow Time Activation Trigger
18
C. Full View Otoscope Lens
D. Light On/Off Button
