Note
Caution symbol indicates that the inner speculum should never be placed in the ear without an Outer Dis-
•
posable Speculum attached to it.
Inner Speculum
A.
Flow Time Activation Trigger
B.
4.1.1 Speculum
Warning
Never place the inner speculum directly into the patient's ear.
•
An outer disposable speculum should always be placed on the delivery head prior to performing an irrigation on a patient.
The outer disposable speculum is intended to be single-use only.
4.1.2 Lens
The Lens can be cleaned with a cleaning cloth like the Natus Medical optical cleaning cloth (part # 7590527). If the lens is
mis- handled and broken a new lens can be purchased. Slide the broken lens out and slide the new lens into place. See
Section
9.1 for an Accessories list.
Natus Medical – ICS® AirCal
]
4 ICS AirCal Delivery Head & Foot Switch
Full View Otoscope Lens
C.
Light On/Off Button
D.
