4.0 MEASURE SAMPLE
4.01
4.02
4.01 What is MEASURE SAMPLE
MEASURE SAMPLE allows as many readings as required but does not store the data for later use. If a 3M
Clean-Trace Luminometer printer is used, results may be printed as they are produced as long as the printer is
turned on and connected while the measurement is performed.
NOTE: To store the data, refer to Section 5 PROGRAM MODE.
4.02 How to Test Using MEASURE SAMPLE

Measuring Samples

To measure a sample, press the SELECT key. The screen will
display the word MEASURING and a series of "count-up" blocks
will appear.
The screen will then display the result in Relative Light Units
(RLU).
What is MEASURE SAMPLE
How to Test using MEASURE SAMPLE
Turn the 3M™ Clean-Trace™ NGi Luminometer on. When
initialized the screen will display the MAIN MENU:
The cursor will be pointing at MEASURE SAMPLE. Insert a 3M
test device into the 3M™ Clean-Trace™ NGi Luminometer (see
section 2.06)
