2.08 Low Power Mode

If the 3M™ Clean-Trace™ NGi Luminometer is switched on but
left unattended for some time during operation, the instrument
will switch to Low Power Mode in order to conserve battery
power. During normal operation this will occur approximately 30
seconds after the backlight has switched off.
The Low Power Mode screen is displayed opposite. Low Power
Mode can also be entered by pressing and holding the top left
green function button when in 'Main Menu' display.
Pressing any green button (except red power button) on the
3M™ Clean-Trace™ NGi Luminometer will return the instrument to the screen displayed before the Low Power
Mode was activated.
If the backlight time is set to "On" (see section 6.09), Low Power Mode can only be entered using the "Back"
button in the 'Main Menu' screen.
2.09 PC Communications
In order to communicate between the 3M™ Clean-Trace™ NGi Luminometer and 3M™ Clean-Trace™ Online
Software ensure that the luminometer is connected to the PC via the USB cable or through the 3M™ Clean-
Trace™ Docking Station, which in turn is connected to the PC via the USB cable.
The screen shown on the right is displayed when the PC is
communicating with the 3M™ Clean-Trace™ NGi Luminometer
during the transfer of sample plans or results.
