Single Monitor Extra Tall Desk Mount
Instruction Manual
SKU: STAND-V011/W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v011
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V011/W
Summary of Contents for Vivo STAND-V011/W
- Page 1 Single Monitor Extra Tall Desk Mount Instruction Manual SKU: STAND-V011/W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v011 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22 lbs Failure to do so may result in serious injury. (10 kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Fully loosen the knob on Clamp (D). STEP 2: Option A - Desk Clamp Connect Clamp (D) to Lower Pole (A) using M6x16mm Screws (S-A) and 3mm Allen Wrench (T-A). - Page 4 STEP 2: Option B - Grommet Using a phillips screwdriver, remove the screw from Clamp (D) and disassemble. Set Knob (D1) aside. Connect Grommet Plate (H) to Bottom Pole (A) using M6x16mm Screws (S-A) and 3mm Allen Wrench (T-A). Remove adhesive backing from Soft Pad (I) and adhere to Grommet Plate (H). Lower Pole (A) &...
- Page 5 STEP 3 Install Middle Pole (B) and Top Pole (C) to Lower Pole (A). Slide Pole Cable Clips (L) and Arm (E) onto assembled pole and tighten with 6mm Allen Wrench (T-C). Insert Pole Cap (G) into Top Pole (C). Attach Arm Cable Clips (K) to Arm (E).
- Page 6 STEP 5 Place VESA Plate (F) with monitor on Arm (E) and secure with M6 Security Nut (S-B). STEP 6 Route cables through Arm Cable Clips (K) and Pole Cable Clips (L).
- Page 7 STEP 7 Adjust the monitor tilt using 5mm Allen Wrench (T-B). Adjust as desired.
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
