Single Monitor Extra Tall Desk Mount
Instruction Manual
SKU: STAND-V011
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v011
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAND-V011 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vivo STAND-V011

Summary of Contents for Vivo STAND-V011

  • Page 1 Single Monitor Extra Tall Desk Mount Instruction Manual SKU: STAND-V011 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v011 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22 lbs Failure to do so may result in serious injury. (10 kg) Phillips Screwdriver ASSEMBLY STEPS ASSEMBLE POLE SET Remove the grub screws with provided Allen wrench (O). Connect the poles (A) by threads. Install the previously removed grub screws and fasten them with the Allen wrench (O).
  • Page 4 STEP 1 (Continued) Option B: Grommet Base with Existing Hole If existing grommet hole comes with a plastic protector, remove it to ensure a flat surface before installing the desk mount. Install grommet base plate (M) to the pole (A) using x3 M5x14 bolts (F). See Figure 4. Attach soft pad (T2) to the grommet base plate (M) , see Figure 5.
  • Page 5 STEP 3 OPTION A: Flat Back Monitor OPTION B: Curved Back Monitor Attach the VESA plate (E) to the monitor with Attach the VESA plate (E) to the monitor with M4x30 M4x12 thumb bolts (Q). bolts (R) and M4 spacers (S). NOTE: Hand tighten screws to avoid over NOTE: Hand tighten screws to avoid over tightening.
  • Page 6 STEP 5 Tighten the bolt with the supplied Allen wrench (O) to fix the tilt angle. To level the monitors, remove the nut (H) and turn the bolt with the Allen key (O) to raise or lower the monitor. Replace nut (H) after the adjustment.
  • Page 7 STEP 6 Use the supplied Allen key set (O) to make any necessary adjustments. Manage cables and store Allen keys (O) in wire clip (N1) for future use.
  • Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
