DESCRIPTION

2. Description
The ULTIMA
calibrated at the factory ready for installation.
The instrument components vary somewhat depending on the particular model.
All models are provided with either ¾" NPT or M25 x 1.5 cable entries.
2.1.

General View Gas Monitor

ULTIMA –
Fig. 1
1 Housing cover with viewing window
2 Sensor electronics with optional LEDs and display
3 Display
4 Housing ( flameproof enclosure)
5 Sensor housing
6 Sensor module
7 Sensor Guard
8
® 3 TM
X instruments are housed in a flameproof enclosure and are
1 2
Gas Monitor (ULTIMA XE shown here)
3
® 3 TM
ULTIMA X
4
5
6
7
