3.1. CHECKING THE SHIPMENT

The received valve must be checked to ensure that it is adapted to the working
conditions in the classified area and the conditions stated in the order

3.2. DELIVERY AND UNPACKING

3.2.1. Delivery
3.2.2. Unpacking

3.3. IDENTIFICATION

In the case of ATEX valves, additional identification will be established with the following:
The temperature class and the maximum surface temperature depend on the temperature of the product to
be stirred and the ambient temperature.
Temperature
class
T6
T5
T4
T3
Maximum surface temperature for explosive dust atmospheres
Maximum
surface
temperature
T85 °C
T100 ºC
T125 ºC
T 200 °C

3.4. LOCATION

3.5. FLOW DIRECTION

3.6. OVERFLOW VALVE POSITION

3.7. ASSEMBLY

To reduce the risk of static electricity, the assembly must be earthed to ensure
electrical continuity between the pipes and the valve
_______________________________________________________________________________________________
ED. 11/2022

3. Receiving and installation

II 2G Ex h IIB T6...T3 Gb
II 2D Ex h IIIB T85ºC...T200
Temperature class for explosive gas atmospheres
Product temperature (in process
or cleaning)
≤ 60 °C
≤ 75 °C
≤ 110 °C
≤ 140 °C
Product temperature (in process
or cleaning)
≤ 85 °C
≤ 100 °C
≤ 125 °C
≤ 200 °C
o
C Db
Room temperature
-20 °C to +40 °C
Room temperature
-20 °C to +40 °C
5
3. RECEIVING AND INSTALLATION OVERFLOW VALVE
