Packaging Contents

• 2 x Mounting Brackets

System Requirements

• ST121R or the receiver/remote unit included with
ST121UTP and ST122UTPA

Installation

Wall/Surface Mounting
Along either side of the ST121 series receiver units are 2
1.
screws. Remove them.
Place the slotted side of one of the brackets against the
2.
side of the STS121 series receiver units, so the screw
holes are visible through the slots.
Using the screws that were previously removed, secure
3.
the bracket against the receiver unit.
Repeat steps 2 and 3 for the opposite side of the
4.
receiver unit.
Mount the completed receiver unit to a flat, stable
5.
surface and attach using the appropriate hardware
(screws, bolts, etc.) (not included) for the surface type.
For the most up-to-date information, please visit: www.startech.com
*actual product may vary from photos
Manual Revision: 06/22/2011
