Superheat controller, Type EKE 1A, 1B, 1C, 1D
Figure 48: Uploading the settings to EKE
Table 20: KoolProg main Menu Summary
Parameter Group
Reference
Control
Defrost Sequence
Alarm configuration
IO config
Sensor's configuration
Valve Configuration
External reference configuration
Display
Communication
Service
4.2.4 Copy to device- Uploading configuration file to KoolProg:
From the parameter selection menu, any change made can be saved as file using the saving options, save or save as,
also you can know the folder containing these files by clicking the folder icon. To upload a configuration file. Click
on browse, select the file you saved from the parameter selection menu, then click open, then Start.
Figure 49: Uploading files through copy-to-device menu
© Danfoss | Climate Solutions | 2022.06
Setup description
Main switch, Mode selection
General control parameter for example selecting control mode, protection function ext.., it is divided into 3
sections:
Control Basic, Control Advanced, Control heatpump
Parameters about the defrost mode
Alarm parameters
Confuguring For analog and digital inputs
Configuring pressure and temperature sensor
Configure settings for the valve
For more settings for External reference and the AI4
Display Settings of the MMI screen, and passwords and logout configuration
-Communication settings (controller address, communication baud rate for CANbus and Modbus)
-Signal Sharing settings
Service Mode allows Entering
-Manual mode, Service Mode and Applying factory default.
