Banner A-GAGE High-Resolution MINI-ARRAY MAHE6A Instruction Manual page 21

Array Length Straight Scan
325 mm (12.8 in)
488 mm (19.2 in)
650 mm (25.6 in)
812 mm (32.0 in)
975 mm (38.4 in)
1138 mm (44.8 in)
1300 mm (51.2 in)
1463 mm (57.6 in)
1626 mm (64.0 in)
1788 mm (70.4 in)
1951 mm (76.8 in)
Note: Scan times are exclusive of serial communication transmission times.
Maximum Scan Time (in milliseconds)
Single-Edge
Scan
Step 2 Beams
10.6 1.9
15.0 2.1
20.1 2.1
24.9 2.1
30.0 2.1
34.5 2.1
39.3 2.1
44.0 2.2
48.0 2.3
53.6 2.3
58.4 2.3
www.bannerengineering.com - Tel: + 1 888 373 6767
Double-Edge Scan
Step 4 Beams Step 8 Beams
8.1 5.1
11.5 6.8
14.9 8.5
18.3 10.1
21.7 11.8
25.0 13.5
28.4 15.2
31.8 16.9
35.1 18.6
38.5 20.3
41.9 21.9
®
A-GAGE High-Resolution MINI-ARRAY
Step 16 Beams Step 32 Beams
3.6 3.0
4.5 3.4
5.3 3.9
6.1 4.2
7.0 4.7
7.9 5.1
8.7 5.5
9.5 5.9
10.4 6.4
11.2 6.8
12.1 7.2
®
2.7
3.0
3.2
3.5
3.6
3.8
4.1
4.3
4.5
4.7
4.9
