  • Page 1 PSS u2 ES 4DOD 0.5A Control system PSS u2 Remote I/O system PSS u2 Operating Manual-1003613-EN-01...
  • Page 2 Preface This document is a translation of the original document. All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made for internal purposes. Suggestions and comments for improving this documentation will be gratefully received.
  • Page 3: Table Of Contents

    Section 7 Wiring General wiring guidelines 7.1.1 Connection mechanism for terminal blocks Terminal configuration Section 8 Operation Display elements and messages Section 9 Technical details Section 10 Order reference 10.1 Product 10.2 Accessories Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 4: Operating Manual Pss U2 Es 4Dod 0.5A

    This operating manual explains the function and operation, describes the installation and provides guidelines on how to connect the product. This documentation is valid for the product PSS u2 ES 4DOD 0.5A. It is valid until new doc- umentation is published.
  • Page 5 Introduction INFORMATION This gives advice on applications and provides information on special fea- tures. Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 6: Overview

    Details of the terminal blocks that can be used are available under "Intended Use". Module features Using the product PSS u2 ES 4DOD 0.5A: Electronic module with digital outputs and expanded diagnostics for standard applications The product has the following features: 4 Digital outputs –...
  • Page 7: Safety

    Use of the module outside the areas described in this manual, Any use of the module that is not in accordance with the technical details. The module PSS u2 ES 4DOD 0.5A may be used in conjunction with the following terminal block:...
  • Page 8: Warranty And Liability

    Any type of modification has been made (e.g. exchanging components on the PCB boards, soldering work etc.). 3.3.3 Disposal When decommissioning, please comply with local regulations regarding the disposal of electronic devices (e.g. Electrical and Electronic Equipment Act). Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 9: Function Description

    The value that is to be used as the substitute value can be configured. Substitute values may be: Output switched off (default value) Output switched on Last valid value Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 10: Reaction Times

    – The module switches off the voltage at the digital outputs. Standby mode – All module functions are inactive. – The LEDs for displaying the module and terminal status are switched off. Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 11: Address Assignment

    1: The signal in the PIO corresponds to the Bit 1 Valid bit of output O1 output signal Bit 2 Valid bit of output O2 Bit 3 Valid bit of output O3 Bit 4-7 None Constant "0" Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 12: Installation

    6.1.1 Dimensions The dimensions include the backplane, electronic module and terminal block. 12,5 51,1 111,1 Fig.: Dimensions in mm, including backplane, electronic module and terminal block Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 13: Inserting And Removing An Electronic Module

    6.2.1 Inserting an electronic module 1. Insert the electronic module into the suspen- sion lug on the back- plane 2. Press the electronic module downwards until you hear it click into place. Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 14 Installation 3. Insert the terminal block into the suspen- sion lug on the module. 4. Press the terminal block downwards until you hear it click into place. Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 15: Removing An Electronic Module

    A new electronic module can be inserted during operation. Effects: Module bus communication between the other modules is not interrupted. The head module may need to be configured and restarted in order for the new module to be detected. Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 16: Wiring

    The minimum cable cross section for field connection terminals on the terminal blocks is 0.15 mm (AWG26). The maximum cable cross section for field connection terminals on the terminal blocks is 1.5 mm with ferrules (AWG14) Use copper wiring. Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 17: Terminal Configuration

    Actuators supplied via the 0 V periphery Terminal configuration supply 1: Output O0 3: 0 V Periphery Supply 5: Output O1 7: 0 V Periphery Supply 9: Output O2 11: 0 V Periphery Supply 13: Output O3 15: 0 V Periphery Supply Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 18: Operation

    The module status display See module's dia- and the terminal status display gnostic log on the relevant output flash synchronously Short circuit/overload/under- voltage Temperature warning: Too See module's dia- warm (1) gnostic log Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 19 After the "too hot" message has been received, if the temperature drops back below the "too warm" threshold value, the module will switch to an error-free state. Legend LED on LED flashes LED flashes briefly LED off Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 20: Technical Details

    60068-2-30, EN 60068-2-78 Ambient temperature In accordance with the standard EN 60068-2-14 Temperature range 0 - 55 °C Storage temperature In accordance with the standard EN 60068-2-1/-2 Temperature range -40 - 70 °C Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 21 2500 V Mechanical data Material Housing Mounting type plug-in Dimensions Height 110,8 mm Width 12,5 mm Depth 72,5 mm Weight 33 g Where standards are undated, the 2015-04 latest editions shall apply. Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
  • Page 22: Order Reference

    Coding elements Product type Features Order No. PSS u2 A CE E (10 pc.) Coding elements, 10 pieces 328 860 PSS u2 A CE T (10 pc.) Coding strip, 10 pieces 328 861 Operating Manual PSS u2 ES 4DOD 0.5A 1003613-EN-01...
