MultiDSU Configuration

Configuring the MultiDSU involves completing all the necessary
connections, including connecting a cable between the MultiDSU and
your DTE device, connecting your PC or terminal to the command port,
connecting the point-to-point T1 line or back-to-back cable and power,
setting up the PC or terminal to configure the MultiDSU, and finally
configuring the MultiDSU using the Configuration procedure provided in
this chapter.
Server
Server
PC
Router
MultiDSU
T1 Network
MultiDSU
PC Router
LAN 2
Figure 2-1. CSU Long Haul Application
LAN 1
PC
Workstation
Data Port
Data Port
PC
Workstation
