Specifications
T1 Line
• Single T1 Line port with synchronous data format
• AMI or B8ZS line coding
• D4 Superframe or Extended Superframe framing support
• 1 to 24 channels at 56 kbps or 64 kbps each
• T1 line connector is an RJ48 jack
Data Port
• Single (V.35 DCE) port for synchronous data
• Operation at data rates from 56 kbps to 1.536 Mbps
• Local and remote loopback capability
• Extensive built-in test capabilities
Electrical/Physical/Environmental
• Voltage - 115v AC, 50/60 Hz (for power adapter)
• Power - 10 watts (est.)
• Dimensions - 6" W x 1.625" H x 9.00" L
• Weight - 2.0 pounds
• Temperature
Operating: - 32° to 122° F (0° to 50° )
Storage: - 4° to 158° F (-20° to 70° )
• Relative Humidity - Up to 95%, non-condensing
14
- 15.24 cm x 4.13 cm x 22.86 cm
