MultiArray User Guide
Technical Specifications
The MultiArray
Dimensions
Height:
Width:
Depth:
Weight:
Power Supply
AC Input
Operating Range:
Frequency:
Current:
Fuse:
Efficiency:
DC Output
Output:
Load Regulation:
Line Regulation:
Transient Time:
Ripple:
Hold Time:
PG Delay:
Safety
Over Voltage Protection:
Over Current Protection:
Environmental
Temperature:
Humidity:
Fan Rating:
Noise:
8
III
conforms to the following specifications:
10.75" (27 cm)
19"
(48 cm)
25"
(63.5 cm)
100 lbs. (45.35 kg)
115-230 VAC
180-270 VAC switch (switch must change on all four power supplies)
47-63 Hz
6A @ 115V
3A @ 230 V
5A @ 115V, 60 Hz
2.5A @ 230V, 50 Hz
80%
+5V @ 60A (70A peak)
+12V @ 28A
-5V @ 1A
-12V @ 1A
±5% (+5, +12)
±10% (-5, -12)
±1% (+5,+12) ±2% (-5,-12)
50ms max
±1% (p-p)
16ms min
100-500ms after 5V output
120% (+5)
130%
0-40
o
C
10% - 90% RH
35cfm (thermostatically controlled) each fan
30db (A) each fan
