Signal Quality +CSQ

This command will return the raw RSSI data, raw Ec/Io, and the channel frame error rate.
Description:
Values: <raw rssi>
75-110
255
<raw Ec/lo>
0-15
255
<fer>
0-100%
255
Command syntax: AT+CSQ
Syntax:
Command
AT+CSQ

Facility Lock +CLCK

This command is used by the application to lock, unlock, or interrogate an ME or network facility <fac>.
Description:
When changing a lock state, a password value must be included in the command even though passwords
are not currently enforced for these facilities. Any 4-digit sequence can be entered for the password value.
This command is also used to allow control of the call barring supplementary service. Barring calls or
querying the status of call barring is possible for Data and Voice Calls, except Emergency Voice Calls.
Values: "AO"
<mode>
"AI"
<mode>
"PB"
<mode>
"DT"
<mode>
<passwd>
Syntax (for Facility Lock):
Command syntax: AT+CLCK= <fac>,<mode>[,<passwd>]
Response syntax: +CLCK: <status>
Command
AT+CLCK?
Note: Get facility lock status
AT+CLCK="AO",1,1234
Note: Bar Outgoing Calls
AT+CLCK="AI",1,1234
Note: Bar Incoming Calls
AT+CLCK="AO",9
Note: Query outgoing call
barring status
Multi-Tech Systems, Inc. CDMA Wireless AT Commands (PN S000294J)
valid value range in units of -dBm
represents an unknown signal quality
valid value range in units of -dB
represents an unknown signal quality
Traffic channel error rate
represents an unknown signal quality
Possible Responses
+CSQ: <raw rssi>,<raw Ec/Io>,<fer>
OK Note: <raw rssi>, <raw Ec/lo>, and <fer> as defined above
BAOC (Bar Outgoing Calls)
Allow all outgoing calls
0
Allow outgoing calls only for phonebook entries (use ATD> command) and emergency
1
voice calls
Allow emergency voice calls only
2
Query status
9
BAIC (Bar Incoming Calls)
Allow all incoming calls
0
Allow incoming calls only for phonebook entries (match number in phonebook) and
1
emergency voice calls
Allow emergency voice calls only
2
Query status
9
Note: Setting this facility to 0 will force the "AO" facility to 0.
BAMC (Bar Outgoing Phonebook Match Calls)
Allow all outgoing calls
0
Allow outgoing calls only for phonebook entries
1
Query status
9
Note: Setting this facility to 0 will force the "AO" facility to 0.
BADC (Bar Data Calls)
Allow data calls
0
Barr data calls
1
Query status
9
Use any four digit value. (e.g. 1234)
Possible Responses
+CLCK:("AO",1),("AI",1),("PB",1),("DT",1)
OK
Note: Outgoing call barring is enabled, Incoming call barring is enabled,
match string from phonebook is enabled, Data calls are not allowed
OK
Note: Outgoing calls are barred
OK
Note: Incoming calls are barred
+CLCK: 1
OK
Note: Outgoing calls are barred
Chapter 24 – Sprint® Specific AT Commands
