Page 1: Multimodem Cdma
® MultiModem CDMA Wireless Modem MTCBA-C User Guide... - Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc., to notify any person or organization of such revisions or changes. Check Multi-Tech’s Web site for current versions of our product documentation.
-
Page 3: Table Of Contents
Fused DC Power Cable Dimensions...27 How to Change the Fuse ...27 Appendix A – Warranty and Repairs ...28 Appendix B - Waste Electrical and Electronic Equipment (WEEE) Statement ...30 Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide Contents Table of Contents... -
Page 4: Chapter 1 - Product Description And Specifications
Specifications Product Description The Multi-Tech MultiModem® CDMA is an external data/fax/voice wireless modem. It also supports mobile originated short message service (SMS) and mobile-terminated SMS. It offers standards-based multi-band CDMA2000 1xRTT performance. This ready-to-deploy, standalone modem allows developers to add wireless communication to products with a minimum of development time and expense. -
Page 5: Safety
Verification of the protection of vehicle electronics should be part of the installation. • The use of an alert device to operate a vehicle’s lights or horn on public roads is not permitted. Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide Chapter 1 – Product Description and Specifications... -
Page 6: Maintenance Of Your Modem
Wireless MultiModem. • In the unlikely event of a fault in the Wireless MultiModem, contact Multi-Tech Tech Support. Your Responsibility This Wireless MultiModem is your responsibility. Please treat it with care respecting all local regulations. It is not a toy. -
Page 7: Specifications
Operating Temperatures Storage Temperatures Humidity Features Certifications Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide Chapter 1 – Product Description and Specifications CDMA2000 1xRTT operation Dual-band 800/1900 CDMA; 800 MHz or 800/1900 MHZ with R-UIM support Up to 153K bps forward and reverse CDMA IS-95-A, IS-95B up to 14.4K bps... -
Page 8: Functions - Cdma Modes
Input supply current in comm. mode at average Tx power Input supply current in idle mode Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide Chapter 1 – Product Description and Specifications The device is permanently powered (when connected to the power supply). -
Page 9: Antenna/Rf Specifications
Terminal Ready. Commonly called “Data Terminal Ready.” This is a readiness signal from the PC. Power. Light is on continuously to when power on. (On the IP model, this LED flashes when power is Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide Chapter 1 – Product Description and Specifications... -
Page 10: Rs232 15-Pin Connector Pinout
AT commands for the CDMA wireless modem are published in a separate Reference Guide included on the MultiModem CD and posted on the Multi-Tech web site. IP commands for CDMA modems are also published in a separate Reference Guide included on the MultiModem CD and posted on the Multi-Tech web site. -
Page 11: Chapter 2 - Activation And Installation
Chapter 2 – Activation and Activate Your Wireless Account Pre-Configured Multi-Tech Products Each Multi-Tech wireless product has been pre-configured to operate on a wireless network. However, Multi- Tech offers some models that are not pre-configured. Activate Your Wireless Account Please see the wireless account Activation Notices located on the MultiModem CD. Choose the one for your wireless network provider and follow the directions to activate your account. -
Page 12: Serial Cable
Chapter 2 – Activation and Installation Serial Cable Connect both sides of the serial and control cable (15-pin Sub D connector on the modem side). Serial & Control Connector To Serial Port of PC Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide... - Page 13 DC fuse/terminal block). Warning Over-voltage protection is provided on the device. To ensure complete protection, you may want to add additional filtering to the DC input Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide Chapter 2 – Activation and Installation...
-
Page 14: Optional - Attach The Modem To A Flat Surface
Slide the mounting bridles into the corresponding slots on the backside of the modem chassis. Attach the modem with two screws to the mounting surface at the desired location on the equipment. Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide Chapter 2 – Activation and Installation... -
Page 15: Install The Modem Driver
Once you have selected your model, click Next>. You will now have to choose the com port to which the Multi-Tech modem is connected. If you know exactly which port your modem is on, click on that port; otherwise, choose COM1 (most common). Click Next >. -
Page 16: Chapter 3 - Using Your Wireless Modem
Help if you cannot find it. A Note About AT Commands CDMA commands is included on the MultiModem CD and on the Multi-Tech Web site. The following two commands let you query signal strength and roaming status. Verifying Signal Strength Using HyperTerminal, type AT+CSQ The modem responds with the received signal strength (rssi) and bit error rate (ber). -
Page 17: Establishing A Voice Call
Disconnect: Type: +++ Wait about two seconds to see an OK response. Then type: ATH Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide (Operation not allowed) Notes: • The phone number you are calling is entered between the displayed brackets. -
Page 18: Using Short Message Services (Sms)
For n, substitute one of the following: The modem will respond OK. Note: The x represents and index location. Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem "UREAD" Show all unread messages. "READ" Show all read messages. -
Page 19: Sms Examples
Receive Example 2: Receive a SMS message and route directly to TE: at+cnmi=2,2,0,0,0 (set modem to receive SMS and route directly to TE) +CMT:"7632273726","06/03/17,13 :38 :22",129,0,3,0,5 (indication that message was received) TEST2 at+cnma (acknowledge that message was received) Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide... -
Page 20: Internet Access
Multi-Tech Systems, Inc. will not be responsible for any charges on your cellular bill. If you have any questions about billing, service plans, service charges, etc., please contact your provider for more information. - Page 21 PC, you will be required to select the proper modem to use. If asked, please select the Multi-Tech wireless modem that has been installed. On the Connection Name screen in the ISP Name box, type in a name for your new connection. You can give it any name that you would like.
-
Page 22: Mobile Phonetools
Chapter 3 – Using Your Wireless Modem Mobile PhoneTools For initial configuration of your wireless device, Multi-Tech offers a Windows® based mobile PhoneTools Mobile PhoneTools is a communication software program included on your MultiModem CD. You can install this program onto your PC and use it for making Internet connections, voice calls, SMS messaging, and email. -
Page 23: Chapter 4 - Troubleshooting And Frequently Asked Questions
Is another program interfering with the communication program? Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide Chapter 4 – Troubleshooting and Frequently Asked Questions Action Provide a power supply in the range of 5 to 32Vdc. Check the cable connection. -
Page 24: Frequently Asked Questions
We have a “Y” cable that splits out to a RJ9 connector that can be used to plug into the receiver of a handset. • Verizon modems currently do not support voice. Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide Chapter 4 – Troubleshooting and Frequently Asked Questions... - Page 25 Bug in the modem. These commands will not store. What is the max supported serial baud rate? • 230,400 bps is the max. Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide Chapter 4 – Troubleshooting and Frequently Asked Questions...
-
Page 26: Chapter 6 - Reference Information
Chapter 6 – Reference Information Chapter 6 – Reference Information Wireless Modem Reference Information Data Cable Diagram – No Voice Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide... -
Page 27: Data Cable Diagram - With Voice
Chapter 6 – Reference Information Data Cable Diagram – with Voice Fused DC Power Cable Dimensions How to Change the Fuse The Fused DC power cable is provided when a single unit is purchased. Multi-Tech Systems, Inc. MultiModem CDMA Wireless Modem User Guide... -
Page 28: Appendix A - Warranty And Repairs
Multi-Tech Warranty Statement Multi-Tech Systems, Inc., (hereafter “MTS”) warrants that its products will be free from defects in material or workmanship for a period of two, five, or ten years (depending on model) from date of purchase, or if proof of purchase is not provided, two, five, or ten years (depending on model) from date of shipment. -
Page 29: Repair Procedures For International Distributors
Repair Procedures for International Distributors International distributors should contact their MTS International sales representative for information about the repair of Multi-Tech product(s). Please direct your questions regarding technical matters, product configuration, verification that the product is defective, etc., to our International Technical Support department at +(763)717-5863. -
Page 30: Appendix B - Waste Electrical And Electronic Equipment (Weee) Statement
Substances) complements the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. The WEEE Directive covers all Multi-Tech products imported into the EU as of August 13, 2005. EU-based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements.
