Chapter 2 – Getting Started

Setup a Wireless Account

Please see the wireless account Activation Notices located on the MultiModem CD. Choose the one for your
wireless network provider and follow the directions to activate your account. These directions may also be included in
your ship kit.
Phone Numbers for the Wireless Modem
Every wireless modem will have its own unique phone number. The phone number may simply be given to you
by your wireless service provider. For GPRS and EDGE, it may also be on the SIM card. Wireless provider
implementations may vary.
Connect Antenna, Ethernet, & Power
Antenna
Connect a suitable antenna to SMA connector. An antenna is supplied with the bundled package ship kit. If
you purchase a single unit, you must supply your own antenna.
Ethernet
Using an RJ-45 Ethernet cable, connect the 10/100 jack to an internal network switch or hub.
Power
Plug one end of the power cord into the device and the other end onto a live power outlet.
Notes
• The PWR LED.
• The Reset Button.
settings.
Antenna
Units shipped with the universal AC power supply are not suited for installation in hazardous
Note:
locations.
Multi-Tech Systems, Inc. MultiModem Wireless Modem with Ethernet Interface (S000375F)
The LED lights after power-up.
PWR
Pressing and holding the
Back Panel
Power Supply Cable
This part of the power supply
cable varies by the region of the
world to which the product is
shipped: NAM / EU / GB / IE
for 5 seconds will restore all factory default
Reset button
Chapter 2 – Getting Started
Ethernet Cable
9
