After clicking the Wizard Setup selection, the Wizards Setup screen displays.

Wizard Setup

IP Configuration
IP Address
Mask
DNS
PPP Configuration
PPP
Dial-on-
Demand
Idle Time Out
Dial Number
APN
Init String
PPP Authentication
Authentication
Type
User Name
Password
A Note About the Access Point Name
The APN (Access Point Name) is assigned by your GPRS or EDGE wireless service provider, but
you may have to ask for it. An access point is an IP network to which a wireless modem connects.
The Web Management software asks for the APN on the Wizard Setup screen and the PPP screen.
Click the Submit button.
5.
Click the Save & Restart button.
6.
Multi-Tech Systems, Inc. MultiModem Wireless Modem with Ethernet Interface (S000375F)
The default is 192.168.2.1. To change it, simply enter your own IP address.
The default is 255.255.255.0
Enter the primary DNS IP address for the system. The default is 0.0.0.0
The default is Enable. This allows the PPP dialer to operate.
The default is Enable. This allows the dial-on-demand feature to operate.
When Disabled, the modem always stays connected.
Sets the amount of time the PPP link stays active before disconnecting. Setting
the value to zero causes the link to stay active continuously.
Enter the dial number. This number connects you to the Internet.
For GPRS and EDGE, the number is *99***1#.
For CDMA, the number is #777
For GPRS and EDGE, enter the APN (Access Point Name). The APN is
assigned by your wireless service provider.
You can set up to 4 modem initialization strings.
Click the button corresponding to the authentication protocol you want to use to
negotiate with the remote peer. PAP, CHAP, or PAP-CHAP.
Default = PAP-CHAP
Enter the PPP User Name. This name authenticates the remote peer. The
default is ipmodule.
Enter the PPP Password. This password authenticates the remote peer.
The default is ipmodule.
Chapter 2 – Getting Started
