Icom iV86 Service Manual Addendum page 68

[MAIN UNIT]
REF PARTS
NO. NO.
S400 2250001090 ENC ED08902OFK150S070C-2015
S401 2260003490 S.SWI TAFG-12W-QR
EP1 8930101610 LCD SRCN-4066-SP-N-W (SHJ)
EP3 6910018460 S.BEA MMZ1005Y102C-T
EP4 6910014690 S.BEA MPZ1608S221A-T
EP400 6910021240 S.BEA MMZ1005A152ET
EP700 6910018460 S.BEA MMZ1005Y102C-T
EP701 6910018460 S.BEA MMZ1005Y102C-T
EP702 6910019900 S.BEA MPZ1608S601AT
EP703 6910016330 S.BEA MMZ1005S 601CT-S
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M .
LOCATION
B
B
B 24.5/20.0
B 78.9/38.3
B 24.0/45.6
B 18.7/45.5
B 26.6/42.1
B 38.3/42.0
H/V
17.4/1.9
33.3/9.5
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-3
