[MAIN UNIT] (for IC-V86 and IC-V86-T)
REF
PART
NO.
NO.
R733
7030016030 S.RES
RMC1/16S-154JTH (150 k)
R734
7030016340 S.RES
RMC1/16S-393JTH (39 k)
R735
7030016050 S.RES
RMC1/16S-102JTH (1 k)
R738
7030016050 S.RES
RMC1/16S-102JTH (1 k)
R739
7030016330 S.RES
RMC1/16S-153JTH (15 k)
R740
7030016910 S.RES
RGC1/16SC393DTH (39 k)
R742
7030016330 S.RES
RMC1/16S-153JTH (15 k)
R745
7030016430 S.RES
RMC1/16S-392JTH (3.9 k)
R746
7030016830 S.RES
RGC1/16SC153DTH (15.0 k)
R750
7030016330 S.RES
RMC1/16S-153JTH (15 k)
R751
7030016020 S.RES
RMC1/16S-104JTH (100 k)
R752
7030016020 S.RES
RMC1/16S-104JTH (100 k)
R753
7030016020 S.RES
RMC1/16S-104JTH (100 k)
R759
7030015970 S.RES
RMC1/16S-103JTH (10 k)
R762
7030016810 S.RES
RGC1/16SC392DTH (3.90 k)
R763
7030017510 S.RES
RGC1/16SC272DTH (2.7 k)
R765
7030016050 S.RES
RMC1/16S-102JTH (1 k)
R767
7030016880 S.RES
RGC1/16SC223DTH (22.0 k)
R771
7030016110 S.RES
RMC1/16S-473JTH (47 k)
R773
7030016050 S.RES
RMC1/16S-102JTH (1 k)
R780
7030016110 S.RES
RMC1/16S-473JTH (47 k)
R781
7030016050 S.RES
RMC1/16S-102JTH (1 k)
R784
7030015960 S.RES
RMC1/16S-472JTH (4.7 k)
R785
7030015950 S.RES
RMC1/16S-152JTH (1.5 k)
R786
7030016410 S.RES
RMC1/16S-561JTH (560)
R787
7030016020 S.RES
RMC1/16S-104JTH (100 k)
R788
7030015970 S.RES
RMC1/16S-103JTH (10 k)
R789
7030016040 S.RES
RMC1/16S-224JTH (220 k)
R790
7030016020 S.RES
RMC1/16S-104JTH (100 k)
R791
7030016020 S.RES
RMC1/16S-104JTH (100 k)
R795
7030015980 S.RES
RMC1/16S-333JTH (33 k)
R796
7030016000 S.RES
RMC1/16S-823JTH (82 k)
R797
7030016110 S.RES
RMC1/16S-473JTH (47 k)
R798
7030016110 S.RES
RMC1/16S-473JTH (47 k)
R799
7030016060 S.RES
RMC1/16S-105JTH (1 M)
R800
7030016060 S.RES
RMC1/16S-105JTH (1 M)
R801
7030015950 S.RES
RMC1/16S-152JTH (1.5 k)
R803
7030015950 S.RES
RMC1/16S-152JTH (1.5 k)
R804
7030015990 S.RES
RMC1/16S-683JTH (68 k)
R805
7030016020 S.RES
RMC1/16S-104JTH (100 k)
R806
7030016060 S.RES
RMC1/16S-105JTH (1 M)
R807
7030016060 S.RES
RMC1/16S-105JTH (1 M)
R808
7030016110 S.RES
RMC1/16S-473JTH (47 k)
R809
7030015910 S.RES
RMC1/16S-101JTH (100)
R810
7030016020 S.RES
RMC1/16S-104JTH (100 k)
R811
7030016060 S.RES
RMC1/16S-105JTH (1 M)
R812
7030016060 S.RES
RMC1/16S-105JTH (1 M)
C4
4030022140 S.CER GRM033B31H102KA12D
C19
4030022140 S.CER GRM033B31H102KA12D
C20
4030022100 S.CER GRM0332C1H100JA01D
C22
4030022140 S.CER GRM033B31H102KA12D
C23
4030022160 S.CER GRM033B31A104KE84D
C24
4030022160 S.CER GRM033B31A104KE84D
C25
4030022260 S.CER GRM033R60J105MEA2D
C26
4030022160 S.CER GRM033B31A104KE84D
C28
4030022160 S.CER GRM033B31A104KE84D
C29
4030022140 S.CER GRM033B31H102KA12D
C32
4030022160 S.CER GRM033B31A104KE84D
C33
4030022160 S.CER GRM033B31A104KE84D
C35
4030022140 S.CER GRM033B31H102KA12D
C36
4030022260 S.CER GRM033R60J105MEA2D
C37
4550007520 S.TAN
F931A106MAABMA
Eqv.
4550009370 S.TAN
267E1002106MR533
C38
4030022090 S.CER GRM0332C1H330JA01D
C42
4030022140 S.CER GRM033B31H102KA12D
C45
4030022140 S.CER GRM033B31H102KA12D
C46
4030022080 S.CER GRM0332C1H101JA01D
C47
4030022140 S.CER GRM033B31H102KA12D
C49
4030022140 S.CER GRM033B31H102KA12D
C52
4030022120 S.CER GRM0332C1H470JA01D
C53
4030022140 S.CER GRM033B31H102KA12D
C54
4030022140 S.CER GRM033B31H102KA12D
C57
4030026690 S.CER RF15N100G500CT
C58
4030023090 S.CER 0402B102K500CT
C59
4030022920 S.CER 0402N820J500CT
C62
4030022740 S.CER 0402N220J500CT
C64
4030022140 S.CER GRM033B31H102KA12D
C65
4030023450 S.CER 0603N100D500CT
C67
4030023700 S.CER 0603N390J500CT
C68
4030022640 S.CER 0402N101J500CT
C69
4030023500 S.CER 0603N150J500CT
C71
4030022160 S.CER GRM033B31A104KE84D
C73
4030023090 S.CER 0402B102K500CT
C75
4030026740 S.CER RF15N5R0B500CT
C76
4030023520 S.CER 0603N180J500CT
C79
4030022140 S.CER GRM033B31H102KA12D
C81
4030026590 S.CER RF15N180J500CT
C82
4030022640 S.CER 0402N101J500CT
C84
4030023090 S.CER 0402B102K500CT
C86
4030026570 S.CER RF15N120J500CT
C88
4030026700 S.CER RF15N1R0B500CT
C89
4030026590 S.CER RF15N180J500CT
C90
4030026690 S.CER RF15N100G500CT
C92
4030026710 S.CER RF15N2R0B500CT
C93
4030026590 S.CER RF15N180J500CT
C94
4030026750 S.CER RF15N7R0C500CT
C95
4030022740 S.CER 0402N220J500CT
C101
4030022740 S.CER 0402N220J500CT
C109
4030022260 S.CER GRM033R60J105MEA2D
C110
4030022260 S.CER GRM033R60J105MEA2D
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION
M.
LOCATION
B
34.8/37.4
T
41.3/37.2
B
36.1/37.8
B
13.9/40.3
B
15.5/40.3
T
B
38.8/37.9
B
15.5/39.4
T
B
39.5/36.3
T
17.6/37.2
T
16.3/38.0
B
18.6/38.1
B
B
50.9/43.5
B
52.5/43.5
B
25.8/40.8
B
50.9/44.4
B
37.1/41.6
B
37.1/42.5
T
33.8/37.4
T
35.0/37.7
B
42.0/40.0
B
41.5/42.4
B
41.5/41.5
B
41.1/40.0
T
36.9/38.3
T
37.9/37.1
T
13.1/31.0
T
14.0/31.0
B
23.3/30.4
B
21.6/30.0
T
20.3/28.0
T
21.9/28.0
B
11.7/30.0
B
11.7/29.1
B
23.0/47.2
B
31.1/33.5
B
20.4/29.6
T
17.9/30.3
B
50.0/31.9
B
50.9/32.6
B
34.3/32.6
T
19.2/32.2
T
17.9/32.2
B
18.4/44.3
B
19.3/42.8
B
28.6/30.1
B
37.8/32.1
B
32.8/26.4
B
50.2/19.5
B
35.7/27.1
B
50.8/19.5
T
B
38.5/30.1
B
47.0/12.0
B
47.0/12.6
B
47.9/12.3
B
45.1/12.8
B
45.1/12.2
B
39.3/26.7
B
B
B
B
B
B
39.5/11.1
B
36.6/22.5
B
39.8/20.2
B
34.3/11.8
B
36.6/20.9
B
34.2/14.8
B
26.1/17.5
B
33.5/13.5
B
20.9/24.2
B
B
22.9/10.9
B
24.1/10.9
B
19.1/26.4
B
B
16.1/27.9
B
18.8/13.6
B
16.8/23.8
B
T
22.2/18.1
B
18.8/12.7
B
14.0/26.5
B
14.9/16.8
B
12.8/20.9
B
12.4/16.8
B
15.2/18.0
B
15.4/24.1
B
10.4/20.9
B
15.1/19.3
B
B
B
B
B
