Icom iV86 Service Manual Addendum page 14

February 2021
The underlined parts have been updated from the previous version of the addendum, or from the original page.
[MAIN-A UNIT] (for IC-G86)
REF PART
NO. NO.
J700 6450000131 CON HSJ1102-018540
J701 6450002530 CON HSJ4456-010320
DS400 5030004550 LCD GP11538A6
DS401 5040003500 S.LED HT-191 UYG-K828
DS402 5040003500 S.LED HT-191 UYG-K828
MC700 7700003280 S.MIC SPU0410HR5H-PB-7
S400 2250001090 ENC ED08902OFK150S070C-2015
S401 2260003490 S.SWI TAFG-12W-QR
EP1 8930101610 LCD SRCN-4066-SP-N-W (SHJ)
EP3 6910018460 S.BEA MMZ1005Y102C-T
EP4 6910014690 S.BEA MPZ1608S221A-T
EP400 6910021240 S.BEA MMZ1005A152ET
EP700 6910018460 S.BEA MMZ1005Y102C-T
EP701 6910018460 S.BEA MMZ1005Y102C-T
EP702 6910019900 S.BEA MPZ1608S601AT
EP703 6910016330 S.BEA MMZ1005S 601CT-S
EP704 6910018460 S.BEA MMZ1005Y102C-T
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
T
T
T
B
B
B 24.5/20.0
B 78.9/38.3
B 24.0/45.6
B 18.7/45.5
B 26.6/42.1
B 38.3/42.0
B 37.0/45.7
(Amended page)
H/V
52.8/4.6
48.3/4.6
36.6/6.6
17.4/1.9
33.3/9.5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-6b
