Icom iV86 Service Manual Addendum page 6

February 2021
The underlined parts have been updated from the previous version of the addendum, or from the original page.
4-2 TRANSMIT ADJUSTMENTS (CONTINUED)
ADJUSTMENT
TRANSMIT 1
OUTPUT POWER
-Verification-
(Extra High)
2
3
(High) 4
5
6
(Middle) 7
8
9
(Low) 10
11
12
TRANSMITTING 1
CURRENT
-Verification-
2
3
4
SPURIOUS 1
EMISSION
-Verification-
2
3
4
(Amended page)
ADJUSTMENT ITEM
DISPLAY
• Connect the RF power meter to the
antenna connector.
• While transmitting, adjust the
connected DC power supply
voltage to 7.5 V.
• Transmitting
• Connect the ammeter between the
JIG battery case and the DC power
supply.
• Transmitting
• Connect the spectrum analyzer to
the antenna connector through the
attenuator.
• Transmitting
SETTING CONDITION
4-5b
OPERATION
4.5~6.5 W
(If out of the specified range,
adjust the output power by [VOL],
then push [# ENT]•[
6.0~8.0 W
(If out of the specified range,
adjust the output power by [VOL],
then push [# ENT]•[
4.5~6.5 W
(If out of the specified range,
adjust the output power by [VOL],
then push [# ENT]•[
2.0~3.0 W
(If out of the specified range,
adjust the output power by [VOL],
then push [# ENT]•[
0.25~1.5 W
(If out of the specified range,
adjust the output power by [VOL],
then push [# ENT]•[
Less than 2.0 A
Less than −60 dBc
].)
].)
].)
].)
].)
