ASSEMBLY INSTRUCTIONS
ROGER RABBIT
VINYL GARDEN FENCE
(24" W X 22" H)
WWW.ZIPPITY-OUTDOOR.COM
WWW.ZIPPITY-OUTDOOR.COM
ASSEMBLY
INSTRUCTIONS
3-PACK
ZP19056
30 MIN
Approximate assembly time for 3 fence panels
Want to see a video on how to
assemble this product?
Scan the QR code
ZP19056
1
VER. 090722
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Zippity ROGER RABBIT ZP19056
Summary of Contents for Zippity ROGER RABBIT ZP19056
- Page 1 ASSEMBLY VINYL GARDEN FENCE INSTRUCTIONS 3-PACK ZP19056 (24” W X 22” H) 30 MIN Approximate assembly time for 3 fence panels Want to see a video on how to assemble this product? Scan the QR code WWW.ZIPPITY-OUTDOOR.COM WWW.ZIPPITY-OUTDOOR.COM VER. 090722...
- Page 2 If you experience any further trouble with your product, please contact our customer service department. parts.nychbrands.com support@zippity-outdoor.com 704-892-5222 877-234-6196 Customer service agents are available to take calls weekdays from 8am- 5pm EST. If you call outside of business hours, please leave a voicemail.
- Page 3 ZP19056 ASSEMBLY INSTRUCTIONS 24 in 1 in 1 1/4 in 1 in WWW.ZIPPITY-OUTDOOR.COM...
- Page 4 Bottom Rail (3) 1½" x 1½" x 24" 1½" x 1½" x 24" ¾" Self-Tapping Stainless Steel Screw (42) Bag A Picket (24) Post (6) ¼" x 1¼" x 21½" " x 1½" x 23¾" 1/8" Steel Drill Bit (1) WWW.ZIPPITY-OUTDOOR.COM...
- Page 5 STEP 2.2 Position (2) Posts as shown. Slide top rail over posts and align pre-drilled holes. Drive (4) ¾” Self-Drilling Stainless Steel Screw into the pre-drilled holes. Align Tabs facing down WWW.ZIPPITY-OUTDOOR.COM...
- Page 6 Use the 1/8" Drill Bit to drill (4) total holes in the post anchor through the pre-drilled holes in the bottom rail. Fasten together through the pre-drilled holes in the bottom rail with (4) ¾” self-drilling stainless steel screws. Align WWW.ZIPPITY-OUTDOOR.COM...
- Page 7 Rotate the Pickets fence frame into the so that the picket holes post tabs are in the top and facing up. bottom rails. ASSEMBLE ADDITIONAL PANELS STEP 4: STEP 4.1 Repeat Steps 1-3 to assemble the other two fence panels. WWW.ZIPPITY-OUTDOOR.COM...
- Page 8 STEP 5.2 Loosen the top 6” of ground with claw hammer. Add water to loosen soil. Block of wood Use a block of wood to protect the post, and lightly hammer the posts into the ground. WWW.ZIPPITY-OUTDOOR.COM...
- Page 9 Use a 1¾” diameter auger bit (commonly used for planting tulips) as illustrated ($15-$20 on Amazon.com). Drill a hole about 12” to 16” deep at the desired location, and fill the holes with water as illustrated. Push the fence posts into the holes. WWW.ZIPPITY-OUTDOOR.COM...
- Page 10 STEP 5.4 If ground is too hard, dig two 8” diameter 8” deep holes to accommodate two posts each as shown below. 8” diameter 8” deep. STEP 5.5 Level the fence panel, backfill excavated dirt, and tamp as necessary. WWW.ZIPPITY-OUTDOOR.COM...
- Page 11 Straight Line Applications: Using (2) Joiner Clips and (4) ¾” self-drilling stainless steel screws. connect the panels as shown below. Corner Applications: Using (2) joiner clips and (4) ¾” self-drilling stainless steel screws connect the panels at a 90° angle as shown below. WWW.ZIPPITY-OUTDOOR.COM...
- Page 12 ZP19056 ASSEMBLY INSTRUCTIONS 6935 Reames Rd. Ste. K. Charlotte, NC 28216 support@zippity-outdoor.com 704-892-5222 877-234-6196 WWW.ZIPPITY-OUTDOOR.COM WWW.ZIPPITY-OUTDOOR.COM...
