ASSEMBLY INSTRUCTIONS
WASHINGTON
VINYL GATE KIT WITH
FENCE WINGS
(30"H X 60½"W)
Approximate assembly time
Want to see a video on how to
WWW.ZIPPITY-OUTDOOR.COM
WWW.ZIPPITY-OUTDOOR.COM
45 MIN
assemble this product?
Scan the QR code
ASSEMBLY
INSTRUCTIONS
ZP19049
ZP19049
1
VER. 020821
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Zippity WASHINGTON ZP19049
Summary of Contents for Zippity WASHINGTON ZP19049
- Page 1 ZP19049 ASSEMBLY INSTRUCTIONS WASHINGTON ASSEMBLY INSTRUCTIONS VINYL GATE KIT WITH FENCE WINGS ZP19049 (30”H X 60½”W) 45 MIN Approximate assembly time Want to see a video on how to assemble this product? Scan the QR code WWW.ZIPPITY-OUTDOOR.COM WWW.ZIPPITY-OUTDOOR.COM VER. 020821...
- Page 2 If you experience any further trouble with your product, please contact our customer service department. parts.nychbrands.com support@zippity-outdoor.com 704-892-5222 877-234-6196 Customer service agents are available to take calls weekdays from 9am- 5pm EST. If you call outside of business hours, please leave a voicemail.
- Page 3 ZP19049 ASSEMBLY INSTRUCTIONS 3 in Ground 2 in WWW.ZIPPITY-OUTDOOR.COM...
- Page 4 ⅞” x 1½” x 26½” ⅞” x 1½” x 41¼” Steel Screw (40) (Bag A) ⅛” Black Self-Drilling Stainless Steel Screw (14) (Bag B) Gate Top Rail (1) ¹⁄₁₆” Drill Bit (1) 1½” x 1½” x 36¼” 1½” x 1½” x 36¼” WWW.ZIPPITY-OUTDOOR.COM...
- Page 5 Fasten (2) ¾” self-drilling stainless steel screws into the gate rail. Next, fasten (2) ¾” self-drilling stainless steel screws into the gate post. Repeat this process for the other three internal corners. WWW.ZIPPITY-OUTDOOR.COM...
- Page 6 The tab of the picket will snap into the gate bottom rail when fully inserted. STEP 3.2 Pressure fit (2) Post Caps down over the gate posts. The post caps will lock into place when fully inserted. WWW.ZIPPITY-OUTDOOR.COM...
- Page 7 Steel Screws (N). ¼” STEP 4.2 Align the Latch Finger to the top gate rail and pre-drill four holes into the gate rail as shown. Fasten (4) ½” black self-drilling stainless steel screws to lock the latch finger in place. WWW.ZIPPITY-OUTDOOR.COM...
- Page 8 Note the direction of the stakes. STEP 5.2 Insert a picket (numbered 1) down through the horizontal top rail and into the horizontal bottom rail. Repeat to assemble the second gate wing. WWW.ZIPPITY-OUTDOOR.COM...
- Page 9 Loosen the top 6” to 8” of the ground using a claw hammer or similar tool. Add water to soften the soil. Use a block of wood to protect the top of the post and gently hammer each post into the ground until the bottom horizontal rails are roughly 2” above the ground. WWW.ZIPPITY-OUTDOOR.COM...
- Page 10 Use a 1¾” diameter auger bit (commonly used for planting tulips) as illustrated ($15-$20 on Amazon.com). Drill a hole about 12” to 16” deep at the desired location, and fill the holes with water as illustrated. Push the fence posts into the holes. WWW.ZIPPITY-OUTDOOR.COM...
- Page 11 Backfill and compact dirt around the base of each post to strengthen the unit. STEP 6.5 Finish the assembly by pushing the post caps down over the top of the posts as illustrated. The post caps will lock into place. WWW.ZIPPITY-OUTDOOR.COM...
- Page 12 Fasten each hinge with (2) ½” black self-drilling stainless steel screws. STEP 7.2 Align the Latch Catch with the latch finger and pre-drill two holes into the horizontal top rail of the gate wing. Fasten with (2) ½” black self-drilling stainless steel screws. WWW.ZIPPITY-OUTDOOR.COM...
- Page 13 STEP 8: STEP 8.1 Follow the instructions included in your Washington Picket Fence Kit (ZP19048). Connect the horizontal top and bottom rails of the gate and fence panels using the supplied joiner clips in the Washington Picket Fence Kit. WWW.ZIPPITY-OUTDOOR.COM...
- Page 14 ZP19049 ASSEMBLY INSTRUCTIONS 6935 Reames Rd. Ste. K. Charlotte, NC 28216 support@zippity-outdoor.com 704-892-5222 877-234-6196 WWW.ZIPPITY-OUTDOOR.COM WWW.ZIPPITY-OUTDOOR.COM...
