ELECTRIC BICYCLE METER KT—LCD10YN Product User Manual
Under the setting maximum riding speed interface, if there's no button operation
on the meter for more than 1 minute, and then the meter will automatically return to
display 1, and the original set values will be saved.
After finishing the maximum riding speed setting, Press
the current set values and enter into the next setting.
○

Wheel Diameter

After finishing the maximum riding speed setting, enter the wheel diameter setting
interface, and then the wheel diameter display column flashes. Press
button (DOWN) to choose the corresponding wheel diameter specification to a
selected vehicle. The selection range of wheel diameter specifications are 16 species such
as 5,6,8,10,12,14,16,18,20,22,24,26,27.5,700C，28 and 29 inches.
Under the wheel diameter setting interface, if there's no button operation on the
meter for more than 1 minute, and then the meter will automatically return to display
1, and the original set values will be saved.
After finishing the wheel diameter setting, press
Setting interface of maximum trip speed
Setting Interface of Wheel Diameter
- 17 -
button (SW) to save
button (UP) or
button (SW) to save the
