1.Main Unit Installation

Step1, Peel off the protecting
mask of main unit.

2.Sensor Installation

Step 1, Switch the
channels in order
POWER ON
Step 3, Remove the the insulation strip
Switch to CH1
Switch to CH2
Switch to CH3
AC Hole
Step 2,Plug the AC Adaptor
to a powered outlet.
Step 2, Load the 2xAA batteries
in 3 minutes to ensure RF
signal received in time.
2
Button Description
1. Top button: Adjust the backlight or turn on / off the snooze
function.
2. " SET " button：Enter into time setting.
3. " " button：Check alarm time,turn on/off alarm,enter into
alarm setting.
4. " ▲/CH " button：Clear sensors data and re-registration
or increase the data.
5. " ▼/RCC " button：RCC function or decrease the data.
6. " ALERTS " button：Check or enter into temperature
alerts setting.
7. " MEM " button：Check or clear Max/min record.
