BALDR B0359WST2H2P User Manual

Wireless color weather station with temperature alerts
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
WIRELESS COLOR WEATHER STATION
WITH TEMPERATURE ALERTS
We thank you for your purchase of Baldr wireless color
weather station with temperature alerts. It has been designed
and constructed using innovative components and techniques
to enable the perfect display. Please read the instructions
carefully to become familiar with the properties and functions
before you use the unit.
For the start-up of this device:
Main unit by AC adaptor (included) and 1x CR2032 (included)
Sensor by 2 x AA batteries (not included)
MODEL:B0359WST2H2P
(NO RCC VERSION)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B0359WST2H2P and is the answer not in the manual?

Questions and answers

Related Manuals for BALDR B0359WST2H2P

Summary of Contents for BALDR B0359WST2H2P

  • Page 1 (NO RCC VERSION) WIRELESS COLOR WEATHER STATION WITH TEMPERATURE ALERTS We thank you for your purchase of Baldr wireless color weather station with temperature alerts. It has been designed and constructed using innovative components and techniques to enable the perfect display. Please read the instructions carefully to become familiar with the properties and functions before you use the unit.

  • Page 2: Product Overview

    PRODUCT OVERVIEW MAIN UNIT 1. Weather forecast Weather forecast for next 12-24 hours 2. Calendar display 3. Weekdays in 7 languages 4. Dual alarm function...

  • Page 3: Outdoor Temperature And Humidity

    5. Current time 12/24 hour format selectable 6. Indoor temperature and humidity 7. Outdoor temperature and humidity 8. Max/min record of indoor temperature and humidity 9. Max/min record of outdoor temperature and humidity 10. Low battery indication 11. High/ low temperature warning 12.
  • Page 4 Notes: 1. The default year is 2020, if the weekday display is incorrect . Please confirm year was set correctly. (for manual setting only) 2. The CR2032 cell battery is for memory function (included), Please do not used as power supply. If you need to replace the cell battery, please take out the part device as shown in the figure below, load new battery matching the polarity （+and-).

  • Page 5: Outdoor Sensor

    OUTDOOR SENSOR 1. Signal light 2. Hanging hole 3. Battery compartment 4. Channel 1-2-3 switch FEATURES • Up to 3 RF channels for outdoor sensors (only one sensor included) • Comfort level indication • Calendar, alarm and snooze function • Time display in 12/24H •...

  • Page 6: Package Content

    1 x AC Adaptor 1 x CR2032 Cell Battery 1 x User Manual GETTING START BALDR recommends high quality alkaline or lithium batteries for the best product performance. Heavy duty or rechargeable batteries are not recommended. MAIN UNIT INSTALLATION Remove the cell battery’s Insulating strip ,then plug the adaptor to a powered outlet.

  • Page 7: Sensor Setup

    SENSOR SETUP • Switch the Channel 1-2-3 of the senor to any channel you want. For example, you can set to Channel 1 for the sensor. But please ensure the main unit are set to the same channel before synchronization. Special note: Press “▲/ CH” button on the main unit to set the channel.

  • Page 8: Manual Settings

    Temperature Display Date Date Format Unit 1st.Jan 2020 ℃ Weather Alarm Time (From Monday to Friday) 7:00 Sunny To Cloudy (From Saturday to Sunday) 8:00 Alarm OFF RF Signal Receiving After power on, It will start receiving outdoor sensors’ signal for 3 minutes.

  • Page 9: Alarm Function

    6. Press “ SET ” to select Year. Setting range: 2000-2099. Press “▲/ CH ” or “▼” button to adjust the value. 7. Press “ SET ” to select Month & Date display format. Default setting : D/M. Press the“▲/ CH ” or “▼” button to select M/D or D/M format.

  • Page 10: Alarm Time Setting

    3. Touch top button to exit and return to time display mode. 4. If no operation for 5 seconds, it will automatically exit . Alarm Time Setting 1. When in alarm time display mode ,press “ ” button to select alarm mode you want (the selecting order is (1-5)→...
  • Page 11 OPERATION GUIDELINES MAX AND MIN RECORD 1. Press “MEM” button to check outdoor and indoor max/min temperature and humidity. 2. The checking order is : Max Record→Min Record→Exit. The value will display for 5 seconds. 3. When in Max Record or Min Record display mode. Press and hold the “MEM”...

  • Page 12: Temperature Alerts

    5. Accuracy: For temperature between 0°C~50°C,the accuracy is ± 1°C, if out of this range the accuracy will be ± 2°C; Temperature resolution is 0.1°C(0.1°F). 6. Press “SET ” button to select the temperature unit °C/°F (Refer to Manual Settings point 6). TEMPERATURE ALERTS Check and Turn ON/OFF Alerts 1.
  • Page 13 2. Alerts setting order: Outdoor High Temperature Alert→ Outdoor Low Temperature Alert → Indoor High Temperature Alert →Indoor Low Temperature Alert → Exit. 3. Press “▲/ CH ” or “ ▼ ” button to adjust the value. Hold to adjust quickly. 4.

  • Page 14: Weather Forecast

    5. Humidity resolution:1% . Tips: The reading will be more accurate if it is placed at the same position for half an hour after power on. WEATHER FORECAST • The weather forecast icon will show after power on. There are 5 kinds of weather modes: Sunny, Sunny To Cloudy, Cloudy, Rainy, Snow.

  • Page 15: Adjustable Backlight

    CALIBRATION Baldr weather stations were calibrated precisely at our manufacturing facility, but if you want the data of this product to be consistent with the reading of the equipment you are more trusted or more used to, you can manually calibrate the indoor temperature, humidity and barometer values.

  • Page 16: Troubleshooting

    TROUBLE SHOOTING Problem Possible Solution Flashing of the outdoor reading is generally an indication of wireless interference. 1. Bring the sensor and main unit indoors, side by side and remove batteries from each. Outdoor reading 2. Make sure the CH 1-2-3 switch on both is flashing or units match.
  • Page 17 “LL.L” will display on temperature screen for indication. If your BALDR product does not operate properly after trying the troubleshooting steps, please contact the seller on your order page or shoot an email to: service@baldr.com.
  • Page 18 PLACEMENT INSTRUCTION BALDR sensors are sensitive to surrounding environmental conditions. Proper placement of both the main unit and outdoor sensor are critical to the accuracy and performance of this product. Main Unit Placement Place main unit in a dry area free of dirt and dust. To help ensure an accurate indoor temperature measurement, be sure to place the Main unit away from heat sources or vents.

  • Page 19: Warranty

    Collection of such waste separately for special treatment is necessary. WARRANTY BALDR provides a 1-year limited warranty on this product against manufacturing defects in materials and workmanship. Warranty service can only be performed by our authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to us, or our authorized service center.
  • Page 20 To receive warranty service, the purchaser must contact with BALDR nominated service center for the problem determination and service procedure. Thank you for your choice of BALDR products! www.baldr.com...
