Advantech TPC 51T 3BE Series User Manual

Industrial touch panel computers with intel atom processors or intel celeron processors
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
TPC-xx51T-x3BE 電腦
Industrial Touch Panel
®
Computers with Intel
Atom™
®
®
Processors or Intel
Celeron
Processors

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPC 51T 3BE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech TPC 51T 3BE Series

Summary of Contents for Advantech TPC 51T 3BE Series

  • Page 1 User Manual TPC-xx51T-x3BE 電腦 Industrial Touch Panel ® Computers with Intel Atom™ ® ® Processors or Intel Celeron Processors...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
  • Page 4 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
  • Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 6 Caution! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dis- pose of used batteries according to the manufacturer's instructions. Danger d'explosion si la pile est remplacée de fa?on incor- recte. Rem- placez seulement avec le même type ou équivalent recom- mandé...

  • Page 7: Table Of Contents

    Contents Chapter General Information ......1 Introduction ....................2 Specifications .................... 2 1.2.1 System Kernel................2 1.2.2 I/O Ports..................2 1.2.3 O/S support................... 2 1.2.4 Safety and Environment..............3 LCD Specifications..................3 Table 1.1: LCD Specifications ............. 3 Touchscreen Specifications ..............4 Power ......................
  • Page 8 Intel® Trusted Execution Engine Driver Installation........ 43 Windows 7 USB 3.0 Driver Installation ........... 45 Advantech EC Driver Installation ............48 Advantech EC Brightness Control Tool Installation ........ 50 Advantech EC Watchdog Timer Driver Installation......... 52 Advantech LMsensor Driver Installation ..........55...

  • Page 9: Chapter 1 General Information

    Chapter General Information...

  • Page 10: Introduction

    Introduction The TPC-XX51T Touch Panel Computer is a state-of-the-art Human Machine Inter- face featuring displays ranging from 12", 15" and 17" and an Intel® Atom™ E3845 ® 1.9 GHz / Intel Celeron J1900 2.0GHz Quad-core Processor. The key features are as follows: True-flat touch screen ...

  • Page 11: Safety And Environment

    1.2.4 Safety and Environment Safety FCC Class A  CE certificated  The front bezel is compliant with IP66 for true flat models and IP65 for the TPCs  with the traditional front bezel Environment Operating Temperature:  – -20 ~ 60 °C (-4 ~ 140 °F) Storage Temperature: ...

  • Page 12: Touchscreen Specifications

    Touchscreen Specifications Touch Type: 5- wire Resistive  Base Glass Construction: Tempered glass  Resolution: (follows the resolution of the system)  Light Transmission: 80% ± 3% (Measured by BYK-Gardner)  Controller: USB Interface  Lifespan: 1 million touches at single point ...

  • Page 13: Panel Mounting

    Panel Mounting There is a rubber waterproof gasket on the AL front bezel. Make sure the water- proof gasket is in position before installing TPC into the panel opening. Install the TPC into the panel opening. Take the clamps and long screws from the accessory box. Hook the clamps to the holes around the four sides of the bezel.
  • Page 14 186.3 15.6 227.6 Figure 1.2 TPC-1251T Dimensions TPC-xx51T-x3BE User Manual...
  • Page 15 230.1 307.3 296.89 Figure 1.3 TPC-1551T Dimensions TPC-xx51T-x3BE User Manual...
  • Page 16 272.9 343.4 333.38 Figure 1.4 TPC-1751T Dimensions TPC-xx51T-x3BE User Manual...

  • Page 17: Chapter 2 System Setup

    Chapter System Setup...

  • Page 18: Transport And Unpacking

    Transport and Unpacking When accepting a delivery, please check the packaging for visible transport damage and check the delivery for completeness by comparing it with your order. If you notice any shipping damage or inconsistencies between the contents and your order, please inform the responsible delivery service immediately.

  • Page 19: System Setup

    System Setup You can easily get TPC started by following the steps below. Unpack the TPC package. Check the packing list at the beginning of this man- ual to make sure all items have been included. Figure 2.1 Unpack the Package TPC-xx51T-x3BE User Manual...
  • Page 20 Connect the power connector to the 24 V power lines. The power lines can either be of some power adapter or in-house power source. Figure 2.2 Power Connector and Power Lines Figure 2.3 Power Receptor & Button Pin Assignment Plug the power lines into the system’s power receptor. Attach power to the system.

  • Page 21: Installing Ssd/Dd

    2.2.1 Installing SSD/DD 1. Unscrew the cover by removing screws on the rear of the box. 2. Slide the rear cover of the rear of the box. 3. Remove the rear cover from rear box. 4. Unscrew the SSD/HDD holder plate. TPC-xx51T-x3BE User Manual...

  • Page 22: Installing An Idoor Module

    5. Fasten SSD/HDD with holder plate. 6. Fasten holder plate on the rear cover. 7. Connect SATA cable with SSD/HDD and on-board SATA signal (CN12) and power (CN8) port. 2.2.2 Installing an iDoor Module 2.1 Remove dummy iDoor cover. TPC-xx51T-x3BE User Manual...
  • Page 23 2.2 Insert iDoor module. 2.3 Fasten iDoor module to rear cover using two screws. 2.4 Insert mPCIe module to mPCIe socket (MPCIE1). 2.5 Connect signal with iDoor module and mPCIe module. TPC-xx51T-x3BE User Manual...

  • Page 24: Installing The Drivers

    2.2.3 Installing the Drivers Please go to Advantech's official website to download product information and driv- ers. Note! The drivers and utilities used for the panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest information regarding drivers and utilities.

  • Page 25: Vesa Mounting

    Secure the clamp to the panel using the included screws. VESA Mounting TPC-xx51T-x3BE supports VESA 100x100 standard. M4 x 10 screws are recommended for mounting TPC-xx51T-E3BE with VESA mounting equipment. Affix your VESA mounting equipment to the top of the rear side of TPC-xx51T- x3BE and fasten VESA equipment with TPC-xx51T-x3BE using 4pcs of M4 screws.

  • Page 26: Cabinet Installation And Earth Grounding Setup

    Cabinet Installation and Earth Grounding Setup Follow these steps to setup your TPC system, and pay attention to the ground pin which should be connected to the earth/ground. TPC system should give the best performance for EMI immunity, ESD immunity, Surge immunity and also system iso- lation.

  • Page 27: Power/Digital Ground And Earth/Ground

    Note! Make sure all wires follow the installation guidelines or it may cause issues. Note! If you install a USB device or Mini PCIe card on the TPC system, please double check the voltage between V- and earth/ground, if the voltage is not almost equal with each other, we suggest to short V- and earth/ ground the wiring.
  • Page 28 TPC-xx51T-x3BE User Manual...

  • Page 29: Chapter 3 Features In Windows Embedded

    Chapter Features in Windows Embedded...

  • Page 30: Features In Windows Embedded

    Applying changes to an image applies all changes made to the operat- ing system during a specific period of time. Advantech provides a utility to operate EWF. To enable this utility, follow the steps below: Click Start Menu->All Programs->Advantech->AdvWF and click EWF Utility...

  • Page 31: File-Based Write Filter (Fbwf)

    Writes to folders with write- through exceptions will persist when the device restarts. Advantech provides a utility to operate FBWF. Refer to the steps below if you want to enable it.

  • Page 32: Horm

    Run OSLock, and then system reboot automatically. Open those software that customers want to directly use after system resumes from hibernation. Hibernates via Advantech HORM utility: Click Start Menu->All Programs->Advantech->AdvWF Select "Enable Hibernation" in "Power Options". Open AdvWF and enable EWF After the system is rebooted automatically, open AdvWF and click EWF Utility.
  • Page 33 TPC-xx51T-x3BE User Manual...
  • Page 34 TPC-xx51T-x3BE User Manual...

  • Page 35: Appendix A Serial Port Settings

    Appendix Serial Port Settings...

  • Page 36: Jumper, Dip Switch, And Connector Location

    Jumper, Dip Switch, and Connector Location A.1.1 Board Placement Jumper Setting and Description A.2.1 CMOS Clear Function (CN1) Table A.1: CMOS Clear Function (CN1) CMOS Clear Function Description This jumper is used to select CMOS Clear Enable/Disable Default (1-2) (2-3) Enable (Clear CMOS) (1-2) Disable...

  • Page 37: Connector Pin Definition

    Connector Pin Definition A.3.1 SATA Connector (CN12) Table A.2: 1654004659 Serial ATA 7P 1.27mm 180D(M) DIP WATM- 07DBN4A3B83.12 Signal Description Signal Pair A : TX+/- (Transmit) Signal Pair B : RX+/ (Receive) A.3.2 SATA Power Connector (CN8) Table A.3: WAFER BOX 4P 2.50mm 180D(M) DIP 24W1170-04S10-01 Signal Description +V5SATA...

  • Page 38: Mini Pcie Slot (Minipcie)

    A.3.3 Mini PCIE Slot (MINIPCIE) Table A.4: 1654002538 MINI PCI E 52P 6.8mm 90D SMD AS0B226- S68N7H Supports PCI1.1, PCI1.2 Power Definition Signal Description Signal Description +3.3Vaux / PCI1.1 was +3.3V, Reserved +3.3V PCI1.2 was +3.3Vaux Reserved +1.5V Reserved Reserved The pin to select the Pin 2, 52 power output for...

  • Page 39: Power In Connector (Cn18)

    Table A.4: 1654002538 MINI PCI E 52P 6.8mm 90D SMD AS0B226- S68N7H Supports PCI1.1, PCI1.2 Power Definition Reference clock CLKREQ# request signal 1.5V Open Drain active Low signal. This signal is used to request that the PCI1.1 was +3.3V, +3.3Vaux / system return PCI1.2 was WAKE#...

  • Page 40: Lan Rj45 Connector (Cn7,Cn8)

    A.3.5 LAN RJ45 Connector (CN7,CN8) Table A.6: 1652002996 PHONE JACK RJ45 14P 90D(M) DIP RTA- 195AAK1A RJ45 Pin Signal Description In BASE-T: Media Dependent Interface[0]: MDI0+  1000BASE-T: In MDI configuration, MDI[0]+/- corresponds to  BI_DA+/- and in MDI-X configuration MDI[0]+/- corresponds to BI_DB+/-.

  • Page 41: Usb Connector (Cn10)

    A.3.6 USB Connector (CN10) Table A.8: 1654010199 USB Conn. 2.0+3.0 13P 90D(F) DIP UEA1112C- UHS6-4 Signal Description 1, 10 USB VBUS USB Power output, USB2.0 5V/0.5A and USB3.0 5V/0.9A 2, 11 USB_P- USB 2.0 date - 3, 12 USB_P+ USB 2.0 date + 4,13 Ground for Power return SSRX-...

  • Page 42: Com2 Rs232/422/485 Connector (Cn16)

    A.3.8 COM2 RS232/422/485 Connector (CN16) Table A.10: 1654000056 D-SUB Conn. 9P 90D(M) DIP 070241MR009S200ZU RS232 RS422 RS485 TPC-xx51T-x3BE User Manual...

  • Page 43: Driver Installation & Configuration

    Appendix Driver Installation and Configuration...

  • Page 44: Intel Chipset Software Installation Utility Installation

    Intel Chipset Software Installation Utility Installation Follow the steps below to install the Intel Chipset Software Installation Utility: Launch <Driver Root Path>\Intel Chipset Software Installation Util-ity\Setup- Chipset_XX.X.XX_PV Install SetupChipset.exe Click Next TPC-xx51T-x3BE User Manual...
  • Page 45 Click Accept Click Install Click Finish TPC-xx51T-x3BE User Manual...

  • Page 46: Intel Graphics Driver Installation

    Intel Graphics Driver Installation Follow the steps below to install the Intel Graphics driver: Launch folder <Driver Root Path>\Graphics Driver\Intel EMGD win7 XX bit\ Install Setp.exe Click Next TPC-xx51T-x3BE User Manual...
  • Page 47 Click Yes Click Next Click Install TPC-xx51T-x3BE User Manual...
  • Page 48 Click Next Choose Yes, then click Finish to restart TPC-xx51T-x3BE User Manual...

  • Page 49: Lan Driver Installation

    LAN Driver Installation Follow the steps below to install the LAN driver: Launch folder <Driver Root Path>\LAN\Win7 \Install_Win7_7077_XXX- _XXXXXXXX Install setup.exe Click Next TPC-xx51T-x3BE User Manual...
  • Page 50 Click Install Click Finish TPC-xx51T-x3BE User Manual...

  • Page 51: Intel® Trusted Execution Engine Driver Installation

    ® Intel Trusted Execution Engine Driver Installation Follow the steps below to install the Intel Trusted Execution Engine driver: Launch folder <Driver Root Path>\TXE\Intel TXE Firmware\Win7 Install kmdf-1.11-Win-6.1-x86.msu Click Yes Click Next TPC-xx51T-x3BE User Manual...
  • Page 52 Click Next Click Next Choose Yes, then click Finish to restart. TPC-xx51T-x3BE User Manual...

  • Page 53: Windows 7 Usb 3.0 Driver Installation

    Windows 7 USB 3.0 Driver Installation Follow the steps below to install the Windows 7 USB 3.0 driver: Launch folder <Driver Root Path>\USB3\Win7\SetupUSB3_X.X.X.XX Install Setup.exe Click Next TPC-xx51T-x3BE User Manual...
  • Page 54 Click Yes Click Next Click Next TPC-xx51T-x3BE User Manual...
  • Page 55 Choose Yes, then click Finish to restart TPC-xx51T-x3BE User Manual...

  • Page 56: Advantech Ec Driver Installation

    Advantech EC Driver Installation Follow the steps below to install the EC drivers: Launch folder <Driver Root Path>\EC\Vx.xx.xxxx Install AdvEC_Vx.xx.xxxx.exe Click Next TPC-xx51T-x3BE User Manual...
  • Page 57 Click Install Click Finish Choose Yes, then click OK to restart TPC-xx51T-x3BE User Manual...

  • Page 58: Advantech Ec Brightness Control Tool Installation

    Advantech EC Brightness Control Tool Installation Note! The Advantech EC driver must be installed first Follow the steps below to install the EC brightness control tool: Launch folder <Driver Root Path>\EC Brightness\Vx.xx.xxxx Install AdvECBrightness_Vx.xx.xxxx.exe Click Next TPC-xx51T-x3BE User Manual...
  • Page 59 Click Install Click Finish TPC-xx51T-x3BE User Manual...

  • Page 60: Advantech Ec Watchdog Timer Driver Installation

    Choose Yes, then click OK to restart Advantech EC Watchdog Timer Driver Installation Note! The EC driver must be installed first Follow the steps below to install the EC Watchdog Timer driver: Launch folder <Driver Root Path>\WDT\Vx.xx.xxxx Install AdvWDT_Vx.xx.xxxx.exe TPC-xx51T-x3BE User Manual...
  • Page 61 Click Next Choose Advantech [EC]WDT, then click Next TPC-xx51T-x3BE User Manual...
  • Page 62 Click Install Click Finish TPC-xx51T-x3BE User Manual...

  • Page 63: Advantech Lmsensor Driver Installation

    Choose Yes, then click OK to restart Advantech LMsensor Driver Installation Follow the steps below to install the LMsensor driver: Launch folder <Driver Root Path>\Lmsensor\Vx.xx.xxxx Install AdvLmsensor_EC_Vx.xx.xxxx.exe Next TPC-xx51T-x3BE User Manual...
  • Page 64 Restart Note! Go to Advantech's product support page for the detailed driver user manual. Note! The drivers and utilities used for the panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest information regarding drivers and utilities.

  • Page 65: Appendix Cbios Setup

    Appendix BIOS Setup...

  • Page 66: Entering Setup

    BIOS supports your CPU. If there is no number assigned to the patch code, please contact an Advantech application engineer to obtain an up-to-date patch code file. This will ensure that your CPU's system status is valid.
  • Page 67 The Main BIOS setup screen has two main frames. The left frame displays all the options that can be configured. Grayed-out options cannot be configured; options in blue can. The right frame displays the key legend. Above the key legend is an area reserved for a text messages. When an option is selected in the left frame, it is highlighted in white.

  • Page 68: Advanced Bios Features Setup

    C.1.2 Advanced BIOS Features Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. Users can select any item in the left frame of the screen, such as CPU Con- figuration, to go to the sub menu for that item. Users can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...
  • Page 69 C.1.2.1 ACPI Settings Configuration Enable ACPI Auto Configuration  This item allows users to enable or disable BIOS ACPI auto configuration. Enable Hibernation  This item allows users to enable or disable system ability to hibernate (OS/S4 sleep State). This option may be not effective with some OS. ACPI Sleep State ...
  • Page 70 C.1.2.2 Super I/O Configuration Serial Port 1 Configuration  Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration  Set Parameters of Serial Port 2 (COMB). C.1.2.3 Embedded Controller Configuration TPC-xx51T-x3BE User Manual...
  • Page 71 EC Hardware Monitor  This page displays all information regarding system Temperature/Voltage/Cur- rent. iManager Watchdog IRQ  This item allows users to set the IRQ number of the EC watchdog. EC Watch Dog Function  This item allows users to select the EC watchdog timer. C.1.2.4 S5 RTC Wake Settings TPC-xx51T-x3BE User Manual...
  • Page 72 Wake system with Fixed Time  Enable or Disable System wake on alarm event. Select FixedTime, system will wake on the hr:min:sec specified. C.1.2.5 CPU Configuration Execute Disable Bit  This item allows users to enable or disable Execute Disable Bit. XD can prevent certain classes of malicious buffer overflow attacks when combined with a sup- TPC-xx51T-x3BE User Manual...
  • Page 73 porting OS (Windows server 2003 SP1, Windows XP SP2, RedHat Enterprise 3 update 3). Intel® Virtualization Technology  This item allows users to enable or disable Intel Virtualization Technology. When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology.
  • Page 74 Serial-ATA (SATA)  This item allows users to enable or disable SATA devices. SATA Test Mode  Test Mode enable / disable. SATA Speed Support  Indicates the maximum speed the SATA controller can support. SATA ODD Port  SATA ODD is Port0 or Port1. SATA Mode ...
  • Page 75 C.1.2.8 LAN Controller LAN A Controller  Enable or disable on-board NIC. LAN B Controller  Enable or disable on-board NIC. Wake on LAN Enable  Enable/Disable integrated LAN to wake the system. TPC-xx51T-x3BE User Manual...
  • Page 76 C.1.2.9 CSM Configuration CSM Support  Enable/Disable CSM Support. GateA20 Active  This item is useful when RT code is executed above 1MB. When this is set as "UPON RQUEST", GA20 can be disabled using BIOS services. When it's set as "Always", it does not allow disabling GA20.
  • Page 77 Option ROM Messages  Set display mode for Option ROM. Boot option filter  This option controls Legacy/UEFI ROMs priority. Network  Controls the execution of UEFI and Legacy PXE OpROM. Storage  Controls the execution of UEFI and Legacy Storage OpROM. Video ...
  • Page 78 Legacy USB Support  Enables support for legacy USB. Auto option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only. XHCI Hand-Off  This is a workaround for OS without XHCI hand-off support. The XHCI owner- ship change should be claimed by the XHCI driver.
  • Page 79 C.1.2.11 COM Configuration COM Configuration  Configure Serial Ports to RS-232/ RS-485/ RS422 TPC-xx51T-x3BE User Manual...

  • Page 80: Chipset Configuration

    C.1.3 Chipset Configuration GOP Driver  Enable GOP Driver will unload VBIOS; Disable it will load VBIOS. C.1.3.1 Intel IGD Configuration Intel IGD Configuration  Configure Intel IGD Settings TPC-xx51T-x3BE User Manual...

  • Page 81: Security

    C.1.4 Security Select Security Setup from the Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this sec- tion. To access the sub menu for the following items, select the item and press <Enter>: Administrator Password ...

  • Page 82: Boot

    C.1.5 Boot Setup Prompt Timeout  Number of seconds that the firmware will wait before initiating the original default boot selection. A value of 0 indicates that the default boot selection is to be initiated immediately on boot. A value of 65535(0xFFFF) indicates that firm- ware will wait for user input before booting.

  • Page 83: Save & Exit

    C.1.6 Save & Exit Save Changes and Exit  This item allows you to exit system setup after saving the changes. Discard Changes and Exit  This item allows you to exit system setup without saving any changes. Save Changes and Reset ...
  • Page 84 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2020...
